SMG Tuya Wifi Smart Switch 1CH Relay Module DC5V 12V 24V AC 32V Self-locking RF433 Receiver Timer Work with Alexa Google Home

SMG Tuya Wifi Smart Switch 1CH Relay Module DC5V 12V 24V AC 32V Self-locking RF433 Receiver Timer Work with Alexa Google Home

FOB Reference Price: Get Latest Price

≥10 Pieces

US $5.5

≥100 Pieces

US $5.2

≥10000 Pieces

US $4.9

≥100000000 Pieces

US $2.5

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: MU

Model Number:: MU-TY01 E0801 7-32V+ RF(Function), Tuya Smart Life DC5V 12V 24V 32V Inching Self-Locking Relay Module

Operating Temperature:: -20-70℃

Compatibility:: 1CH Tuya Switch WiFi Switch Module Smart life APP Remote Control

APP:: Tuya/Smart Life

Feature 1:: Inching mode

Feature 2:: Selfing-lock mode

Number:: Tuya wifi switch

Max Current:: 2200W/10A

WIFI Standard:: WIFI 2.4ghz b/g/n(Do not support 5G)

Voltage:: DC 12V 24V 32V DC/AC 7-32V

RF:: support RF433Mhz

Quick Details

Max. Current:: 10A

Max. Voltage:: 32V

Network:: WIFI

Place of Origin:: Guangdong, China

Brand Name:: MU

Model Number:: MU-TY01 E0801 7-32V+ RF(Function), Tuya Smart Life DC5V 12V 24V 32V Inching Self-Locking Relay Module

Operating Temperature:: -20-70℃

Compatibility:: 1CH Tuya Switch WiFi Switch Module Smart life APP Remote Control

APP:: Tuya/Smart Life

Feature 1:: Inching mode

Feature 2:: Selfing-lock mode

Number:: Tuya wifi switch

Max Current:: 2200W/10A

WIFI Standard:: WIFI 2.4ghz b/g/n(Do not support 5G)

Voltage:: DC 12V 24V 32V DC/AC 7-32V

RF:: support RF433Mhz

Product Description

Name	1CH Tuya Switch WiFi Switch Module Smart life APP Remote Control 1Gang Inching Switch Self-locking Smart Home
Max Current	10A/220W
Voltage	AC/DC 7-32V RF 1CH
APP	Tuya/Smart Life
Transportation Mode	Wifi + RF ( rf remote control is not included )

Tuya Smart Life DC 5V 12V 24V 32V Wifi Switch Intelligent Module inching mode RF433 Remote Control Work with Alexa Google Home

This product is a wireless momentary(inching) switch. Users can add the device to the APP in order to remotely control connected home appliances or power circuits.

Note:The relays are switches without output, the power supply input (DC) just for the PCBA.

Supported functions include:

*Remote turn on/off
*Timing Schedules
*Device Sharing
*Group Management
*Works with Amazon Echo, Echo Dot, Amazon Tap
*Works with Google Home

Remote Control

The product enables remote control of home appliances through the APP , available on both Android and iOS.

Inching mode

In inching mode, you can have two wiring ways to select: -Turn on 0.7s and then auto-off /Turn off 0.7s and then auto-on.

How to change the Inching time on the APP?

Enabling this feature will put the device in an automatic state.Each time the device is switched on,it will automatically switch
off after a set period of time. The time range is 1-3659s.

Schedule

Work with Alexa and Google Home

This product is compatible with Amazon Alexa. You can ask Alexa to control the device with the following voice commands.
Try out these phrases ( {deviceName} should be the name of your device):
“Alexa, turn on {deviceName}”
“Alexa, turn off {deviceName}”
“Alexa, schalte Ger?tename ein”
“Alexa, schalte Ger?tename aus”
Also you can ask Google Home to control the device with the following voice commands.
“hey, google, turn on {deviceName}”
“OK, google, turn off {deviceName}”

Smart switch, bid farewell to traditional switching methods

Description

* Brand Name: Scimagic-RC
* Certification: CE
* Origin: CN(Origin)
* State of Assembly: Ready-to-Go
* Model Number: Tuya Smart Life DC5V 12V 24V 32V Inching Self-Locking Relay Module
* Compatibility: All Compatible
* Camera Equipped: No
* Input voltage: DC/AC 7-32V
* Max.Current: 2200W/10A
* WIFI Standard: WIFI 2.4ghz b/g/n(Don't support 5G)
* Working temperature: -20-70℃
* Size: 1ch 69*41*20mm,2ch 120*38*25mm
* Feature 1: Inching mode
* Feature 2: Selfing-lock mode
* RF: support RF433Mhz

Details Images

For Access

For electric motor lock

Packing&Shipping

1 pcs/small packing box, 30-50 pcs/bag 500/carton

Recommend Products

Certifications

After Sales Service

Please contact us anytime if you have any problem about our products.

Company Introduction

MIXIYOU Company is located in Shenzhen and is specialized in producing and developing wireless remote controls, receiver control boards, receiver modules, photocell beam sensors and other products for automation many years.

FAQ

1. How long will delivery take? Generally takes 4-5 working days shipped by DHL, Fdex, TNT, UPS, EMS...... 2. How long for production? For small orders will be dispatched in 2 working days. For orders more than 500pcs, it will take about 5 working days, for customized or special order, will take 15-20 working days. 3. How will my order be sent? Usually for small orders will be sent with express (DHL, FEDEX, UPS, TNT......) 4.What’s your MOQ? Our MOQ is 100 pcs per model for normal orders, mixed order is acceptable. 5. What is a compatible remote? A compatible remote is an aftermarket remote not produced by the same manufacturer as the original but will be compatible with your motor. 6. How is the payment Tern? T/T, Western Union Paypal for small orders or sample orders. 7. Can I customized? Yes, you can send us details or sample, we can develop for you. 8. Are you a manufacture or supplier only? We are manufacture.
