Quick Details
-
Ink Type:
-
UV Ink
-
Place of Origin:
-
Guangdong
-
Brand Name:
-
XBH
-
Voltage:
-
220VAC/380VAC
-
Dimensions(L*W*H):
-
L115*W70.5*H75.5cm
-
Weight:
-
20 KG
-
Marketing Type:
-
New Product
-
Core Components:
-
Other
-
Product name:
-
Portable Mini Wall Printer
-
Print head:
-
High Precision Ep son Printhead
-
printhead number:
-
1-3 pcs
-
Ink colors:
-
CMYK/CMYKW
-
Ink type:
-
uv ink
-
Media Type:
-
Wall surface:Putty wall surface,Latex paint wall,Big white wall
-
Print speed:
-
6-18 sqm/h
-
Printing size:
-
2.5m high x any width,Can be spliced arbitrarily beyond 2.5 meters
-
Image Format:
-
PSD,JPG,JPEG,PNG,TIFF,AI and PDF,etc.
-
Applicatio:
-
Indoor Outdoor Advertisement
Quick Details
-
Print Dimension:
-
2.5m high x any width,Can be spliced arbitrarily b
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Ink Type:
-
UV Ink
-
Place of Origin:
-
Guangdong
-
Brand Name:
-
XBH
-
Voltage:
-
220VAC/380VAC
-
Dimensions(L*W*H):
-
L115*W70.5*H75.5cm
-
Weight:
-
20 KG
-
Marketing Type:
-
New Product
-
Core Components:
-
Other
-
Product name:
-
Portable Mini Wall Printer
-
Print head:
-
High Precision Ep son Printhead
-
printhead number:
-
1-3 pcs
-
Ink colors:
-
CMYK/CMYKW
-
Ink type:
-
uv ink
-
Media Type:
-
Wall surface:Putty wall surface,Latex paint wall,Big white wall
-
Print speed:
-
6-18 sqm/h
-
Printing size:
-
2.5m high x any width,Can be spliced arbitrarily beyond 2.5 meters
-
Image Format:
-
PSD,JPG,JPEG,PNG,TIFF,AI and PDF,etc.
-
Applicatio:
-
Indoor Outdoor Advertisement
|
Product name
|
Portable Mini Wall Printer
|
|
|
Printhead
|
High precision Ep son printhead
|
|
|
Printhead quantity
|
1~3pcs
|
|
|
Ink color
|
cmyk
|
|
|
Machine weight
|
20KG
|
|
|
Power
|
350W
|
|
|
Voltage
|
220VAC
|
|
|
Print speed
|
6-18 sqm/h
|
|
|
Printing size
|
2.5m high x any width,Can be spliced arbitrarily beyond 2.5 meters
|
|
|
Print resolution
|
360×720dpi / 720×1440dpi / 1080×1440dpi / 1440×2880dpi
|
|
|
Image Format
|
PSD,JPG,JPEG,PNG,TIFF,AI and PDF,etc.
|
|
|
Main board
|
8-core high-speed CPU,4GB Memory,120G SSD
|
|
|
The key components
|
1.5m guide rail with four sections,1 laser locator,2 ultrasonic probes,3 Imported servo motor,1 reducer
|
|
|
Applicable medium
|
Wall surface:Putty wall surface, Latex paint wall, Big white wall, Imitation porcelain wall
Other media:Glass, tile, board, Acrylic, PVC and metal plates, etc. |
|
|
3d/5d print function
|
Yes
|
|
|
Wall detection function
|
Wall detection function automatic hyperboloid sensor, up and down bidirectional
Wall detection function detection of ground concave and convex, accuracy up to 1 mm |
|
|
Data recovery after
power failure |
Yes (the software stores data in real time and will not scrap the previous print due to power failure)
|
|
|
Nozzle inspection function
|
Yes (software check head condition)
|
|
|
Color calibration function
|
Yes (Software adjust color)
|
|
|
Print distance adjustment function
|
Yes (print size and distance can be adjusted by software)
|
|
|
UPS battery function
|
Yes (Customer can prepare one)
|
|
|
Print location function
|
Yes (laser red cross positioner to print the picture to the certain position)
|
|
|
Horizontal regulation function
|
Yes (the track has the function of horizontal adjustment)
|
|
|
Folding and disassembly
|
Yes (1.5 meters after folding, a SUV car can fit; Machine can be disassembled into three parts for easy move)
|
|
|
Image Mosaic function
|
Yes (can achieve seamless picture stitching)
|
|
|
Note:
the above parameters are design parameters. In case of any difference, the actual use effect of the equipment shall prevail
|
|
|
1.How many basic colors does the printer uses?
Four colors, CMYK: cyan, magenta, yellow and black,White or Varnish
2.Do you need a flat surface for the wall printer to move along the wall ?
No need for very flat walls, our wall printers print high quality pictures on uneven surfaces.
3.The process to set the printer up on site –how long does it take ?
It takes only 10 minutes to assemble our wall printer.
4.Does the machine move on the running track or does the machine move?
It is the machine that moves on the track, not the track is moving.
5.What type of ink does the printer use and where can I buy from?
The ink of the machine is custom-made, because after our adjustment, this ink is very suitable for the printing process of our machine, and the printed picture is very good. You can contact us to purchase print ink.
6.What type of files can I print with ?
Support JPG, BMP, TIFF, PDF, AI, PSD, CDR, etc.
7.Durability of the ink – is it for interior or exterior applications ?
The room can be kept for 10 years without fading, and the outdoor can be kept for 5 years without fading.
8.What is the print height?
2.5m high x any width,Can be spliced arbitrarily beyond 2.5 meters.
9.What materials can I print on?
Putty wall, latex paint wall, brick wall, diatom mud wall, shell powder, paper, wood.
UV-wall printer can also print on non-absorbent surfaces , such as: Glass, tile, metal.
10.Any defects during the warranty period at your expense?
Non-human damage during the one-year warranty period.
11.Is it possible to enlarge a print at height? So you print out a part of the picture, then set it down
again and continue. Will the photo appear to be in two parts?
again and continue. Will the photo appear to be in two parts?
Of course . You can print the stitches left and right, or you can stitch them up and down. The image printed with the feathering effect does not appear to be two parts. You can watch the video we took.
