Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
one inverter
-
Model Number:
-
FT-2K
-
Output Frequency:
-
50hz/60hz
-
Size:
-
48*30*19cm
-
Weight:
-
16kg
-
Application:
-
Solar Power System Home
-
Product name:
-
Power Inverter
-
Warranty:
-
1 Year
-
Output waveform:
-
Pure Sine Wave Solar Inverter
-
Display:
-
LCD+LED Display
-
Inverter type:
-
Off-grid Solar Inverter
-
Efficiency:
-
90%
-
OEM:
-
Accepted
-
Communication:
-
RS485
-
Certificate:
-
CE FCC
Quick Details
-
Output Current:
-
15a
-
Network:
-
off grid, off grid solar system
-
Customized support:
-
available
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
one inverter
-
Model Number:
-
FT-2K
-
Output Frequency:
-
50hz/60hz
-
Size:
-
48*30*19cm
-
Weight:
-
16kg
-
Application:
-
Solar Power System Home
-
Product name:
-
Power Inverter
-
Warranty:
-
1 Year
-
Output waveform:
-
Pure Sine Wave Solar Inverter
-
Display:
-
LCD+LED Display
-
Inverter type:
-
Off-grid Solar Inverter
-
Efficiency:
-
90%
-
OEM:
-
Accepted
-
Communication:
-
RS485
-
Certificate:
-
CE FCC
Product Description
Specification
|
Model
|
FT-202
|
FT-302
|
FT-402
|
FT-502
|
FT-602
|
|||||
|
Rated power
|
2KW
|
3KW
|
4KW
|
5KW
|
6KW
|
|||||
|
Surge power
|
6KW
|
9KW
|
12KW
|
15KW
|
18KW
|
|||||
|
AC Input & Output
|
|
|
|
|
|
|||||
|
Voltage
|
220VAC
|
|
|
|
|
|||||
|
Selectable Voltage Range
|
165-275VAC (220VAC)
|
|
|
|
|
|||||
|
Frequency Range
|
50Hz/60Hz automatic recognition
|
|
|
|
|
|||||
|
AC Voltage Regulation
(BATT. Mode)
|
(DC Batt.mode)220vac±3%
|
|
|
|
|
|||||
|
Transfer Time
|
≤4ms
|
|
|
|
|
|||||
|
Wave Form
|
Pure Sine Wave
|
|
|
|
|
|||||
|
Transformer type
|
Toroidal
|
|
|
|
|
|||||
|
Transfer efficiency
|
≥85%
|
|
|
|
|
|||||
|
Battery
|
|
|
|
|
|
|||||
|
Battery Voltage
|
12V/24V/48V
|
|
24V/48V
|
|
|
|||||
|
Type
|
Gel/SLA/AGM/Water/Lithium(lifepo4) Battery
|
|
|
|
|
|||||
|
DC Charge Voltage
|
12~16VDC(12V)/20~32VDC(24V)/40~64VDC(48V)
|
|
|
|
|
|||||
|
Overcharge Protection
|
Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm
|
|
|
|
|
|||||
|
AC Charger
|
|
|
|
|
|
|||||
|
Maximum Ac Charge Current
|
35A (adjustable)
|
|
|
|
|
|||||
|
Working mode
|
|
|
|
|
|
|||||
|
01 mode
|
AC mains priority mode
|
|
|
|
|
|||||
|
02 mode
|
ECO mode
|
|
|
|
|
|||||
|
03 mode
|
DC battery priority mode
|
|
|
|
|
|||||
|
04 mode
|
Generator mode
|
|
|
|
|
|||||
|
05 mode
|
Unattended mode
|
|
|
|
|
|||||
|
Communication Port
|
|
|
|
|
|
|||||
|
Type
|
RS485, available for wifi box & external control screen
|
|
|
|
|
|||||
|
Physical
|
|
|
|
|
|
|||||
|
Dimension,
D*W*H(MM)
|
600*380*170
|
|
780*380*280
|
|
|
|||||
|
G.W.(KGS)
|
19
|
21
|
31
|
33
|
35
|
|||||
|
Environment
|
|
|
|
|
|
|||||
|
Humidity
|
0~95%（NO CONDESNSATION)
|
|
|
|
|
|||||
|
Operating Temperature
|
0~60℃
|
|
|
|
|
|||||
|
Storage Temperature
|
0~60℃
|
|
|
|
|
|||||
|
*Product Specifications Are Subject To Change Without Further Notice
|
|
|
|
|
|
|||||
