Quick Details
-
Engine Brand:
-
CHANGCHAI
-
Place of Origin:
-
China
-
Brand Name:
-
LTMG
-
Dimension(L*W*H):
-
2990*1280*2360mm
-
Name:
-
road roller
-
Keywords:
-
road roller 3 ton
-
Product name:
-
construction mashines road roller
-
Rolling width:
-
1000mm
-
Static Linear Pressure:
-
162N/cm
-
Activating force:
-
50Hz
-
Operating weight:
-
3000kg
-
Diameter of vibrating drum:
-
800mm
-
Vibration frequency:
-
50hz
-
warranty period:
-
1 year or 2000 working hours
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
25KW
-
Weight:
-
3 Ton
-
Engine Brand:
-
CHANGCHAI
-
Place of Origin:
-
China
-
Brand Name:
-
LTMG
-
Dimension(L*W*H):
-
2990*1280*2360mm
-
Name:
-
road roller
-
Keywords:
-
road roller 3 ton
-
Product name:
-
construction mashines road roller
-
Rolling width:
-
1000mm
-
Static Linear Pressure:
-
162N/cm
-
Activating force:
-
50Hz
-
Operating weight:
-
3000kg
-
Diameter of vibrating drum:
-
800mm
-
Vibration frequency:
-
50hz
-
warranty period:
-
1 year or 2000 working hours
Product Paramenters
|
Model
|
LTC10
|
LTC20
|
LTC30
|
|
Operating weight
|
800 kg
|
2000 kg
|
3000 kg
|
|
Diameter of vibrating drum
|
φ400 mm
|
φ650 mm
|
φ800 mm
|
|
Rolling width
|
625 mm
|
850 mm
|
1000 mm
|
|
Static Linear Pressure (front/rear)
|
50/70 N/cm
|
105 N/cm
|
162 N/cm
|
|
Centrifugal force
|
20KN
|
20 KN
|
35 KN
|
|
Vibration frequency
|
60 HZ
|
50 HZ
|
50 HZ
|
|
Theoretical amplitude of vibration
|
0.5 mm
|
0.5 mm
|
0.58 mm
|
|
Moving speed range
|
0-3.5 km/h
|
2-5.6 km/h
|
2-5.6 km/h
|
|
Grade ability
|
30%
|
20%
|
20%
|
|
Diesel engine model
Rated rotation speed Rated power |
KM186FAM 3000 r/min
5.7 kw |
Changchai ZN390Q
2400 r/min 25 kw |
ZN390Q
2400 r/min 25 kw |
|
Overall dimensions L W H
|
Open：2450x680x1200mm Folding:1350x680x1850mm
|
2660×1060×2350mm
|
2990×1280×2360 mm
|
Products Details
Mechanical drive , two-speed gears.
Hydraulic vibration, great exciting force with high compaction efficiency.
Hydraulic steering, articulated frame with flexible operation
Electronic control pressurized water spraying system is optional
ODM/OEM
