Engine Ventilation Crankcase Filter Element For Dodge Ram 2500 3500 6.7L Diesel 2007.5-2020 68002433AC 68002433AB 68002433AA

Engine Ventilation Crankcase Filter Element Crankcase Breather Filter Car Auto Filter For Cummins Repair Parts Accessories For Dodge Ram 2500 3500 6.7L Diesel 2007.5-2020 68002433AC 68002433AB 68002433AA 4936636 904418  CV52001

Application:

• For Ram Models:
• For 07.5(Year/Month)-20 Ram 2500 6.7L 2WD and 4WD.
• For 07.5-20 Ram 3500 6.7L 2WD and 4WD.
• For 07.5-20 Ram 4500 6.7L 2WD and 4WD.
• For 07.5-20 Ram 5500 6.7L 2WD and 4WD.
• For Ford Models:
• For 11-20 Ford F550 6.7L.
• For 08-15 Ford F650/ F750 6.7L.
• For International Models:
• For 14-19 International 4300.
• For 16-19 International 7300/4300LP.
• For 19-20 International MV607.
• For Freightliner Models:
• For 08-19 Freightliner B2.
• For 08-13 Freightliner M2 106.
• For 08-09 Freightliner Cargo/M2.
• For 08-17 Freightliner MT55/XC Modular Rail/XC Straight Rail/MB Line/MC Line.
• For 08-18 Freightliner MT45/XB Straight Rail/XC Raised Rail.
• For 13-17 Freightliner S2C.
• For 12-17 Freightliner 108SD.
• For 12-15 Freightliner XB Line.
• For 11-17 Freightliner XC Lowered Rail.

For Other Models:

• For 08-18  Blue Bird All American FE/RE Vision School Bus.
• For 08-10 Sterling Bullet 45/55.
• !!! For Vehicles Equipped with 2007.5 Up 6.7L ISB Cummins Diesel Engine!!!

Vehicle compatibility charts are for REFERENCE ONLY. Please Check your vehicle with OEM below to match your needs.

• OEM:68002433AC, 68002433AB, 68002433AA, 4936636, CV52001, 904418.

Specification:

• 100% quality assurance tested, more responsive, less expensive, easier to install.
• Replace your cracked, clogged or missing original equipment filter.
• Multi-layer high-grade filter, higher filtration efficiency.
• Eliminate fog, aerosol vapor and oil droplets in the engine compartment.
• Reduce fuel consumption, reduce engine maintenance and down time.
• Corrosion resistance, withstand engine oil and heat.
• OEM quality, sturdy housing, tight sealing.
• Replacement is essential for passing state inspection.

Material & Color:

• Material: made of high quality Polypropylene.
• Color: as picture.

Package Included:

• 1x Crankcase CCV Filter. (100% Brand New Never Used Or Installed)

Installation Steps:

1. Open the hood, locate CCV, remove dipstick.
2. Loosen 4 screws(8mm) of cover to take it off. Remove oil fill cap.
3. Remove 8 bolts(8mm) on the crankcase vent cover.
4. Unplug electrical connector in the back left.
5. Open CCV filter cover, pop out the old CCV filter. (Keep mind there are couple houses attached in the back left.)
6. Seat new CCV filter in. Lubricate gaskets for a quick fit.

What is CCV Filter?

• The Crankcase Ventilation Filter(CCV) sits on top of the valve cover, where positive pressure is released, and air intake to and from the atmosphere takes place.
• All 2007.5 and newer 6.7L Cummins engines have a crankcase vent filter that is located on top of the valve cover assembly and under the dress cover.

When Should Replace?

• 1. Vehicle almost traveled 67,500 miles.
• The factory suggested change interval for the CCV is 67,500 miles/100,000km. Due to the fact that the CCV breather tube is routed to the turbo inlet, it's recommended to perform shorter change intervals to help minimize oil vapor coating of the turbo compressor wheel.
  2. Clear warning appears on the dash.
• "Service Perform" message will come up on your dash, which means you need to change CCV Filter to solve this problem.
  3. Crankcase filter is clogged.
• Per Dodge, a message on your overhead console will alert you when the crankcase vent filter becomes clogged.

Why You Need?

• 1. Remove oil particles and other debris in the gases, prevent dirt from getting into the crankcase.
• 2. Help to keep crankcase clean during the engine cooling process.
• 3. Quickly separate oil vapor to prevent excessive oil and gas pressure when the tank is full. The oil vapor will condense the engine oil and reduce its performance if the oil vapor cannot be effectively separated.
• 4. Prevent engine oil to leak out from the crankshaft oil seal, crankcase liner and be lost, resulting in increased fuel consumption.
• 5. Prevent various oil vapors from polluting the atmosphere. If the crankcase filter is not replaced in time, the filtering effect will be greatly reduced, which will have a bad impact on our cars and the environment.

Necessity of Replacement:

• Cummins Filtration's crankcase ventilation systems are innovative products using latest technologies to control oil drip and crankcase emissions in diesel engine applications.
• The Open Crankcase Ventilation (OCV) systems provide superior aerosol filtering of crankcase emissions, commonly known as blow-by. Blow-by is the result of high pressure gases and oils escaping around piston rings and venting to the atmosphere.
• This oily mist attracts dust and airborne particles, resulting in an accumulation of contaminants, both on the engine and on the surface beneath it. This condition increases the clean-up required in the engine compartment, as well as unsightly oil drips on highways, bodies of water, parking lots, crops, garage floors and driveways.
• The benefits of replaces your OCV filter are eliminates oil drips, reduces oil consumption, superior aerosol filtration and collection, reduces engine maintenance and down time and increases engines life.

Note

• Provide Tracking Number With Every Order, Please Buy With Confidence!
• No installation guides are included, we highly recommend to seek professional installation. Any damage during installation will not be refunded.
• Will come with everything you see in the picture. Please allow difference due to manual measurement.
• Please check that the picture matches before purchase. The color of the actual items may slightly different from the listing images due to different computer screen, thanks for your understanding.
• For any inquiries or special requests such as larger amount ordering please write to us.
