Quick Details
-
Warranty:
-
25 Years
-
Brand Name:
-
baoxinda
-
Model Number:
-
550w-600w
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1956*1310*40mm
-
Function:
-
Generate Power
-
Application:
-
Solar Energy Storage Systems
-
OEM order:
-
Acccept
-
Product name:
-
Monocrystalline Silicon Solar Panel
-
Keyword:
-
Monocrystalin Solar Panel
-
Solar cell:
-
Monocrystalline Silicon Cells
-
Junction Box:
-
IP 68 Rated
-
Weight:
-
28.6kg
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Type:
-
standard, Standard Solar Panel
-
Panel Efficiency:
-
550W
-
Warranty:
-
25 Years
-
Brand Name:
-
baoxinda
-
Model Number:
-
550w-600w
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1956*1310*40mm
-
Function:
-
Generate Power
-
Application:
-
Solar Energy Storage Systems
-
OEM order:
-
Acccept
-
Product name:
-
Monocrystalline Silicon Solar Panel
-
Keyword:
-
Monocrystalin Solar Panel
-
Solar cell:
-
Monocrystalline Silicon Cells
-
Junction Box:
-
IP 68 Rated
-
Weight:
-
28.6kg
Products Description
|
580-605W
|
|
|
|
|
|
|||||
|
Peak Power Watts-PMAX (Wp)
|
580
|
585
|
590
|
595
|
600
|
|||||
|
Maximum Power Voltage-VMPP (V)
|
33.8
|
34.0
|
34.2
|
34.4
|
34.6
|
|||||
|
Maximum Power Current-IMPP (A)
|
17.16
|
17.21
|
17.25
|
17.30
|
17.34
|
|||||
|
Open Circuit Voltage-VOC (V)
|
40.9
|
41.1
|
41.3
|
41.5
|
41.7
|
|||||
|
Short Circuit Current-ISC (A)
|
18.21
|
18.26
|
18.31
|
18.36
|
18.42
|
|||||
|
Module Eciency η m (%)
|
20.5
|
20.7
|
20.8
|
21.0
|
21.2
|
|||||
|
Power Tolerance-PMAX (W)
|
0 ~ +5
|
|
|
|
|
|||||
|
NOCT(Nominal Operating Cell Temperature)
|
43°C (±2°C)
|
|
|
|
|
|||||
|
Temperature Coecient of VOC
|
- 0.25%/°C
|
|
|
|
|
|||||
|
Temperature Coecient of ISC
|
0.04%/°C
|
|
|
|
|
|||||
|
STC: Irrdiance 1000W/m2, Cell Temperature 25ºC, Air Mass AM1.5-Measuring tolerance: ±3%
|
|
|
|
|
|
|||||
