Quick Details
-
Brand Name:
-
LEYE
-
Model Number:
-
LY-A03-05
-
tact switch:
-
tact switch with good quality
-
Certification:
-
ROHS
Quick Details
-
Max. Current:
-
50MA
-
Max. Voltage:
-
12V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEYE
-
Model Number:
-
LY-A03-05
-
tact switch:
-
tact switch with good quality
-
Certification:
-
ROHS
|
Rated Current
|
50mA
|
|
Rated Voltage
|
12V
|
|
Contact Resistance
|
≤50mΩ Max
|
|
Insulation Resistance
|
≥100mΩ 100V DC
|
|
Compressive Strength
|
AC250V 50Hz/1min
|
|
Mechanical Life
|
50000 cycles min
|
|
Operating Stroke
|
0.15±0.05mm
|
|
Operating Force
|
160gf/260gf±50gf
|
|
Temperature Range
|
-25℃~+70℃
|
