- Product Details
- {{item.text}}
Quick Details
-
Insulation Material:
-
Rubber
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Dingzun
-
Model Number:
-
heat wire 06
-
Product name:
-
carbon fiber heating wire heater element wire
-
Conductor Wire:
-
Nichrome Copper
-
Key word:
-
heater wire
-
Feature:
-
12k 15k 18k 24k 36k heat cabl
-
Diameter:
-
1.2-8.0mm
-
Inside Structure:
-
Helix
-
Resistance:
-
0.3-2000 Ohms/M
-
Color:
-
Customized
-
Keyword:
-
silicone heating wire
-
Smell:
-
No any smell,friendly
Quick Details
-
Application:
-
Electric Blanket,Heating Pad,Towel Heater
-
Conductor Material:
-
Nichrome/copper/stainless steel
-
Conductor Type:
-
Solid or stranded
-
Insulation Material:
-
Rubber
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Dingzun
-
Model Number:
-
heat wire 06
-
Product name:
-
carbon fiber heating wire heater element wire
-
Conductor Wire:
-
Nichrome Copper
-
Key word:
-
heater wire
-
Feature:
-
12k 15k 18k 24k 36k heat cabl
-
Diameter:
-
1.2-8.0mm
-
Inside Structure:
-
Helix
-
Resistance:
-
0.3-2000 Ohms/M
-
Color:
-
Customized
-
Keyword:
-
silicone heating wire
-
Smell:
-
No any smell,friendly
Product Description
Product Parameter
Single Helix Heating Cable
|
NO.
|
SPECIFICATION
|
DETAILS
|
|
1.
|
Name
|
Single helix heating wire for water pipe heating, floor heating, snow melting, car seat pad heating, heaters and etc
|
|
2.
|
Heating Conductor
|
Nichrome/copper alloy/stainless steel
|
|
3.
|
Inside Structure
|
Helix
|
|
4.
|
Inside Material
|
Fiberglass/Polyester
|
|
5.
|
Insulating layer
|
Silicone Rubber
|
|
6.
|
Voltage
|
5V-350V
|
|
7.
|
Resistance
|
0.8-2000 Ohms/M
|
|
8.
|
Cable Diameter
|
1.5mm-6mm
|
|
9.
|
WATT
|
1-35W/M,As your demand
|
|
10.
|
Temperature Resistant
|
Silicone:230℃
|
|
11.
|
Cable Lifespan
|
Silicone layer cable is 72 months
|
Double Helix Heating Cable
|
NO.
|
SPECIFICATION
|
DETAILS
|
|
1.
|
Cable Diameter
|
2.5MM
|
|
2.
|
Watt
|
3.5-4.2W/M
|
Straight Wire Heating Cable
|
NO.
|
SPECIFICATION
|
DETAILS
|
|
1.
|
Wire Material
|
Nichrome/Copper
|
|
2.
|
Layer Material
|
Silicone
|
|
3.
|
Diameter
|
1.5-2.5mm
|
Carbon Fiber Heat Cable
|
NO.
|
Conductor diameter
|
Cable diameter
|
K
|
Resistance
|
|
1.
|
0.15mm
|
1.6mm
|
1K
|
440 Ω/M
|
|
2.
|
0.25mm
|
1.8mm
|
2K
|
220 Ω/M
|
|
3.
|
0.35mm
|
2.0mm
|
3K
|
133 Ω/M
|
|
4.
|
0.55mm
|
2.2mm
|
6K
|
66 Ω/M
|
|
5.
|
0.65mm
|
2.2mm
|
9K
|
45 Ω/M
|
|
6.
|
0.75mm
|
2.2mm
|
12K
|
33 Ω/M
|
|
7.
|
0.85mm
|
2.5mm
|
15K
|
25 Ω/M
|
|
8.
|
0.95mm
|
2.5mm
|
18K
|
22.5 Ω/M
|
|
9.
|
1.05mm
|
2.7mm
|
21K
|
19 Ω/M
|
|
10.
|
1.15mm
|
3.0mm
|
24K
|
16.5 Ω/M
|
|
11.
|
1.25mm
|
3.0mm
|
27K
|
14.7 Ω/M
|
|
12.
|
1.35mm
|
3.0mm
|
30K
|
13.3 Ω/M
|
|
13.
|
1.45mm
|
3.2mm
|
33K
|
12 Ω/M
|
|
14.
|
1.55mm
|
3.2mm
|
36K
|
11 Ω/M
|
|
15.
|
1.65mm
|
3.3mm
|
39K
|
10.2 Ω/M
|
|
16.
|
1.75mm
|
3.4mm
|
42K
|
9.5 Ω/M
|
|
17.
|
1.85mm
|
3.5mm
|
45K
|
8.86 Ω/M
|
|
18.
|
1.95mm
|
3.6mm
|
48K
|
8.3 Ω/M
|
