Quick Details
-
Brand Name:
-
Haosheng
-
color:
-
Dish brown color,shinnig,bright white,green
-
size:
-
0.1-12mm
-
certification:
-
ISO BV
-
Craft:
-
annealing;acid washing as request
-
magnetism:
-
Y/N
Quick Details
-
Application:
-
Heating
-
Conductor Type:
-
Solid
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Haosheng
-
color:
-
Dish brown color,shinnig,bright white,green
-
size:
-
0.1-12mm
-
certification:
-
ISO BV
-
Craft:
-
annealing;acid washing as request
-
magnetism:
-
Y/N
1. FeCrAl heating wire: OCr27AL7Mo2, OCr21AL6Nb, OCr21AL6, OCr25AL5, OCr23AL5, OCr21AL4, 1Cr13AL4
2. Nichrome heating wire: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30.
3. Product forms and size range: (bare)round wire, ribbon/strip/flat wire, spring, bar/rod
Round wire
0.010-12 mm (0.00039-0.472 inch) Other sizes are available on request.
Ribbon (flat wire)
Thickness: 0.023-0.8 mm (0.0009-0.031 inch)
Width: 0.038-4 mm (0.0015-0.157 inch)
Width/thickess ratio max 60, depending on alloy and tolerance
Other sizes are available on request.
Home applicances - u s ed for heating elements
- electric blankets
- hair dryers
- kettles
- heaters
- snow melting heating cable
- underground heating mats
Industry uses - u sed for industrial stove ovens & furnaces ,machines
- Annealing furnaces
- Salt bath furnace
For installing inside furnaces for bending glass
For sealing vacuum machines, the thickness are 0.20 / 0.25 / 0.30 and width 10 mm / 3 mm/ 4mm / 5 mm
Chemical Content
|
Alloy material |
Chemical composition % |
|||||||||
|
C |
P |
S |
Mn |
Si |
Cr |
Ni |
Al |
Fe |
others |
|
|
max(≤) |
||||||||||
|
Cr20Ni80 |
0.08 |
0.02 |
0.015 |
0.6 |
0.75-1.60 |
20.0-23.0 |
Rest |
≤0.50 |
≤1.0 |
— |
|
Cr30Ni70 |
0.08 |
0.02 |
0.015 |
0.6 |
0.75-1.60 |
28.0-31.0 |
Rest |
≤0.50 |
≤1.0 |
— |
|
Cr15Ni60 |
0.08 |
0.02 |
0.015 |
0.6 |
0.75-1.60 |
15.0-17.0 |
55.0-61.0 |
≤0.50 |
Rest |
— |
|
Cr20Ni35 |
0.08 |
0.02 |
0.015 |
1 |
1.00-3.00 |
18.0-21.0 |
34.5-36.0 |
— |
Rest |
— |
|
Cr20Ni30 |
0.08 |
0.02 |
0.015 |
1 |
1.00-2.00 |
18.0-21.0 |
30.0-31.5 |
— |
Rest |
— |
|
1Cr13Al4 |
0.12 |
0.025 |
0.025 |
0.7 |
≤1.00 |
12.5-15.0 |
— |
3.5-4.5 |
Rest |
— |
|
0Cr15Al5 |
0.12 |
0.025 |
0.025 |
0.7 |
≤1.00 |
14.5-15.5 |
— |
4.5-5.3 |
Rest |
— |
|
0Cr25Al5 |
0.06 |
0.025 |
0.025 |
0.7 |
≤0.60 |
23.0-26.0 |
≤0.60 |
4.5-6.5 |
Rest |
— |
|
0Cr23Al5 |
0.06 |
0.025 |
0.025 |
0.7 |
≤0.60 |
20.5-23.5 |
≤0.60 |
4.2-5.3 |
Rest |
— |
|
0Cr21Al6 |
0.06 |
0.025 |
0.025 |
0.7 |
≤1.00 |
19.0-22.0 |
≤0.60 |
5.0-7.0 |
Rest |
— |
|
1Cr20Al3 |
0.06 |
0.025 |
0.025 |
0.7 |
≤1.00 |
18.0-21.0 |
≤0.60 |
3.0-4.2 |
Rest |
— |
|
0Cr21Al6Nb |
0.05 |
0.025 |
0.025 |
0.7 |
≤0.60 |
21.0-23.0 |
≤0.60 |
5.0-7.0 |
Rest |
Nb add0.5 |
|
0Cr27Al7Mo2 |
0.05 |
0.025 |
0.025 |
0.2 |
≤0.40 |
26.5-27.8 |
≤0.60 |
6.0-7.0 |
Rest |
|
Spring shape:
Bare round wire:
Heating resistance rod:
H eating resistance ribbon/stripe/flat wire :
