New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels
New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels

New Type Longi 400W 405W 410W 415W 420W All Black Solar Panel LR5-54HPB Solar Panels

FOB Reference Price: Get Latest Price
≥15300 Pieces
US $0.23
≥76500 Pieces
US $0.22
≥300000 Pieces
US $0.2
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Warranty:
25 years Power Warrenty, 25 Years Output Power Guarantee
Brand Name:
LONGI
Model Number:
LR5- 54HTB 410-425M
Place of Origin:
Jiangsu, China
Panel Dimensions:
1722*1134*30mm
Solar cell:
182*182mm Half cut cell
Application:
Solar Panel System
Junction Box:
IP68 Rated
Weight:
20.8kg
Glass:
Single glass,3.2mm Coated Tempered Glass
Packaging Configuration:
36 pcs per pallet
Efficiency:
20.7%~21.8%
Material:
Monocrystalline Silicon
Certificate:
TUV/CE/ISO/CQC/PICC

Quick Details

Cell size:
182mmx182mm
Type:
PERC, Half Cell, All Black
Panel Efficiency:
21.0%-21.8%
Warranty:
25 years Power Warrenty, 25 Years Output Power Guarantee
Brand Name:
LONGI
Model Number:
LR5- 54HTB 410-425M
Place of Origin:
Jiangsu, China
Panel Dimensions:
1722*1134*30mm
Solar cell:
182*182mm Half cut cell
Application:
Solar Panel System
Junction Box:
IP68 Rated
Weight:
20.8kg
Glass:
Single glass,3.2mm Coated Tempered Glass
Packaging Configuration:
36 pcs per pallet
Efficiency:
20.7%~21.8%
Material:
Monocrystalline Silicon
Certificate:
TUV/CE/ISO/CQC/PICC
Product Description

ELECTRICAL CHARACTERISTICS

Module Number
LR5-54HTB-410M
LR5-54HTB-415M
LR5-54HTB-420M
LR5-54HTB-425M
Testing Condition
STC NOCT
STC NOCT
STC NOCT
STC NOCT
Maximum Power (Pmax/W)
410 306
415 310
420 314
425 318
Open Circuit Voltage (Voc/V)
38.63 36.27
38.83 36.46
39.03 36.65
39.23 36.83
Short Circuit Current (Isc/A)
13.70 11.07
13.78 11.13
13.85 11.19
13.93 11.25
Voltage at Maximum Power(Vmp/V)
32.36 29.53
32.56 29.71
32.76 29.89
32.96 30.08
Current at Maximum Power(Imp/A)
12.67 10.37
12.75 10.44
12.83 10.50
12.90 10.56
Module Efficiency(%)
21.0
21.3
21.5
21.8
Voc and Isc Tolerance ±3%
Maximum System Voltage DC1500V(IEC)
Mechanical Data of Solar Module
Cell orientation
108Cells
Frame
Anodized Aluminium Alloy
Frame Thickness
30mm
Weight of module
20.8kg
Module Dimensions
1722*1134*30mm
Junction Box
IP68, three diodes
Main Components
Solar Cell
--High Anti-PID resistant --Low breakage rate
--Color sorting ensure consistent appearance on each module
--Service life is as long as 25 years
-- No Busbar


Junction box
--Long service life
--Heat dissipation
-- IP68 protection level
--Conventional standalone edition and engineering custom edition
--Quality diode ensures module running safety

Frame
--Conventional frame
--Boost bearing capability and prolong service life
--Serrated-clip design tensile strength
--Seal-lip design glue injection
--Silver or black frames are optional
