Quick Details
-
Color:
-
VIDEO FULL COLOR, full color
-
Panel Size:
-
640*480*70mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
P2.5
-
Brightness:
-
0-1200, 0-1200cd/sqm
-
pixel density:
-
160000
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
65536
-
Lifespan (hours):
-
100000
-
IP Rating:
-
33
-
HS Code:
-
853120000
-
Resolution:
-
160000/sqm
-
View Angle（H/V）:
-
160/160
-
delivery time::
-
7 to 20 days
-
Certificate:
-
CCC/CE/FCC/ISO9001/ISO14001/ROSH
-
Refresh Rate:
-
>3840Hz
-
After-sales Service Provided:
-
7/24 Technical Guidance
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
JianHe
-
Color:
-
VIDEO FULL COLOR, full color
-
Panel Size:
-
640*480*70mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
P2.5
-
Brightness:
-
0-1200, 0-1200cd/sqm
-
pixel density:
-
160000
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
65536
-
Lifespan (hours):
-
100000
-
IP Rating:
-
33
-
HS Code:
-
853120000
-
Resolution:
-
160000/sqm
-
View Angle（H/V）:
-
160/160
-
delivery time::
-
7 to 20 days
-
Certificate:
-
CCC/CE/FCC/ISO9001/ISO14001/ROSH
-
Refresh Rate:
-
>3840Hz
-
After-sales Service Provided:
-
7/24 Technical Guidance
Technical Parameters
LED Panel Parameters
|
Model
|
P1.25
|
P1.5
|
P1.8
|
P2.5
|
|||
|
LED Type
|
SMD1010
|
SMD1010
|
SMD1515
|
SMD2020
|
|||
|
Physical Density(dot/m
2
)
|
640,000
|
422,500
|
288,906
|
160,000
|
|||
|
Module Size(WxHxD)mm
|
320*160*17
|
|
|
|
|||
|
Module Resolution(WxH)
|
256*128
|
208*104
|
172*86
|
128*64
|
|||
|
Cabinet Size(WxHxD)mm
|
640*480*59
|
|
|
|
|||
|
Cabinet Material
|
Die Casting Aluminum
|
|
|
|
|||
|
Scanning Mode
|
1/64
|
1/52
|
1/43
|
1/32
|
|||
|
Cabinet Flatness(mm)
|
≤0.10
|
|
|
|
|||
|
Grey Scale(bit)
|
16
|
|
|
|
|||
|
Protection Level
|
IP45
|
|
|
|
|||
|
Brightness(cd/m
2
)
|
500~900cd/m
2
|
|
|
|
|||
|
Color Temperature
|
3200~9300K Adjustable
|
|
|
|
|||
|
Brightness Uniformity
|
≥98%
|
|
|
|
|||
|
Viewing Angle
|
≥140°
|
|
|
|
|||
|
Contrast Ratio
|
≥6000：1
|
|
|
|
|||
|
Moduel Input Voltage DC
|
5V
|
|
|
|
|||
|
Max Refresh Rate
|
≥3840Hz
|
|
|
|
|||
|
Input Voltage AC
|
100~240V
|
|
|
|
|||
|
Max Power Consumption
|
≤600W/m
2
|
≤580W/m
2
|
≤480W/m
2
|
≤480W/m
2
|
|||
|
Ave Power Consumption
|
≤200W/m
2
|
≤180W/m
2
|
≤160W/m
2
|
≤160W/m
2
|
|||
|
Working Temperature
|
-20℃~+80℃
|
|
|
|
|||
|
Working Humidity
|
10%~95% Rh
|
|
|
|
|||
|
Installation/Service Method
|
Front Installation/Front Service
|
|
|
|
|||
