Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Huatong
-
Model Number:
-
NMD90
-
Rated voltage:
-
300V
Quick Details
-
Application:
-
Heating
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Solid
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Huatong
-
Model Number:
-
NMD90
-
Rated voltage:
-
300V
Application:
NMD90 cables maybe used for both exposed work in dry location work in dry or damp locations.
The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is - 40 °C . For two-conductor cables and -10°C for three-conductor cables (with suitable handling procedures). Material should be Properly stored above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended applications is 300volts .Consult the Canadian Electrical Code 1 for further Information related to applications.
Standard:
CSA - C22.2 No.48 (non-metallic sheathed cable)
Canadian Electrical Code 1
MD90 with protective covering:
1. Conductor: copper 14AWG to 2AWG or aluminium alloy 8000series 12AWG to 2AWG.
2. Insulation: Polyvinyl chloride (PVC)
3. Protective covering: nylon
3. Jacket: PVC, Heat and moisture-resistant, flame retardant FT1.
Voltage: 300V
Number of conductor: 2 par alle l laid
3 and 4 round laid
cUL Approved file No.:
E487898
Printing on the surface of cable:
* AWG * COR NMD90 NYLON CABLES HT CABLES FT1 300V (-25℃) C(UL) E487898
|
Phase Conductor |
Insulation thickness |
Ground |
Jacket thickness |
Approx.OD of cable |
|||
|
Size (AWG) |
Cores |
Strands |
mm |
Size (AWG) |
Strands |
mm |
mm |
|
14 |
2 |
1 |
0.86 |
14 |
1 |
0.76 |
4.9*9.9 |
|
12 |
2 |
1 |
0.86 |
14 |
1 |
0.76 |
5.3*10.8 |
|
10 |
2 |
1 |
0.86 |
12 |
1 |
0.76 |
5.9*12.3 |
|
14 |
3 |
1 |
0.86 |
14 |
1 |
0.76 |
8.8 |
|
12 |
3 |
1 |
0.86 |
14 |
1 |
0.76 |
9.8 |
|
10 |
3 |
1 |
0.86 |
12 |
1 |
0.76 |
10.9 |
|
8 |
3 |
7 |
1.02 |
10 |
1 |
1.14 |
14.7 |
|
6 |
3 |
7 |
1.30 |
8 |
7 |
1.14 |
18.1 |
Normally in 75 meters or 150 meters per reel.
Plastic reels or plywood reels.
