Quick Details
-
Model Number:
-
CZ-93CPM02
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-5-+65℃ (no icing)
-
Max. Current:
-
6A
-
Operating speed:
-
5mm to 0.5m/s
-
Operation frequency: electrical:
-
30 times/min
-
Vibration:
-
10-55Hz, 1.5mm double amplitude
-
Humidity:
-
below 95%RH
-
Certification:
-
CCC
Quick Details
-
Max. Voltage:
-
8V-250V
-
Place of Origin:
-
ZHE
-
Brand Name:
-
CNTD
-
Model Number:
-
CZ-93CPM02
-
Protection Level:
-
IP65
-
Operating Temperature:
-
-5-+65℃ (no icing)
-
Max. Current:
-
6A
-
Operating speed:
-
5mm to 0.5m/s
-
Operation frequency: electrical:
-
30 times/min
-
Vibration:
-
10-55Hz, 1.5mm double amplitude
-
Humidity:
-
below 95%RH
-
Certification:
-
CCC
Products Description
|
Rating
|
3A 240VAC (A300)
|
|
|
|
|||
|
Operation speed
|
0.1mm-0.5m/s
|
|
|
|
|||
|
Operating frequency
|
Electical: 30 operations/min
|
|
|
|
|||
|
Contact rsistance
|
25mΩ max. (initial value)
|
|
|
|
|||
|
Insulation resistance
|
100mΩ min. (below 500VDC)
|
|
|
|
|||
|
Rated insulation voltage(UI)
|
400V
|
|
|
|
|||
|
Dielectric strength
|
AC2500V/Umip 4KV
|
|
|
|
|||
|
Vibration
|
10~55Hz,1.5mm double amplitude
|
|
|
|
|||
|
Shock
|
Mechanical: Approx. 1,000m/s² (Approx. 100G'S)Malfunction: Approx. 300m/s² (Approx 30G'S)
|
|
|
|
|||
|
Ambient temperature
|
Using: -20~+70℃ (With no icing)
|
|
|
|
|||
|
Humidity
|
<95% RH
|
|
|
|
|||
|
Electrical life
|
150,000 operations above
|
|
|
|
|||
|
Protection level
|
IP65 (IEC Standard)
|
|
|
|
|||
