- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Lovely
-
Model Number:
-
DS-1
-
Product name:
-
Disc Type Liquid Limit Device
-
Drive:
-
manual model
-
Resolution:
-
0.1mm
-
Measuring nonlinear error:
-
better than 2%
-
Contact indication sensitivity:
-
>10M
-
The total weight of the cone:
-
76g ± 0.2g, 100g ± 0.2g
-
Conical angle:
-
30 ° ± 0.2 °
-
Dish drop frequency:
-
120/min (allowable error 15%)
Quick Details
-
Warranty:
-
12 months
-
Power:
-
Electronic
-
Place of Origin:
-
Cangzhou City,China
-
Brand Name:
-
Lovely
-
Model Number:
-
DS-1
-
Product name:
-
Disc Type Liquid Limit Device
-
Drive:
-
manual model
-
Resolution:
-
0.1mm
-
Measuring nonlinear error:
-
better than 2%
-
Contact indication sensitivity:
-
>10M
-
The total weight of the cone:
-
76g ± 0.2g, 100g ± 0.2g
-
Conical angle:
-
30 ° ± 0.2 °
-
Dish drop frequency:
-
120/min (allowable error 15%)
DS-2
Electric
Disc Type Liquid Limit Device
Product Description
Introduction
The dish-type liquid limit machine is used to measure the liquid limit of the soil to
classify the soil. The groover is used to form a groove in the soil, and then the soil
dish is raised to allow the dish to fall several times. When the soil groove is closed to
an appropriate degree, the moisture content of the sample is measured. Designed and
manufactured in accordance with the GB/T21997.1-2008 standard, meeting SL 237-1999 "Geotechnical Test Regulations", JTG E40-2007 "Highway Geotechnical Test Regulations", TB10102-2010 "Railway Engineering Geotechnical Test Regulations", GB/T50123-2019 "Standards for Geotechnical Test Methods", ASTM D4318 "Standard Test Methods for Liquid Limit of Soil" and other method standards. Consistency limits (LL and PL) are important for understanding the stress history and general properties of construction soils. Estimation of the plasticity index (LL-PL) is important for classifying soils, especially in highly expansive clays.
The dish-type liquid limit machine is used to measure the liquid limit of the soil to
classify the soil. The groover is used to form a groove in the soil, and then the soil
dish is raised to allow the dish to fall several times. When the soil groove is closed to
an appropriate degree, the moisture content of the sample is measured. Designed and
manufactured in accordance with the GB/T21997.1-2008 standard, meeting SL 237-1999 "Geotechnical Test Regulations", JTG E40-2007 "Highway Geotechnical Test Regulations", TB10102-2010 "Railway Engineering Geotechnical Test Regulations", GB/T50123-2019 "Standards for Geotechnical Test Methods", ASTM D4318 "Standard Test Methods for Liquid Limit of Soil" and other method standards. Consistency limits (LL and PL) are important for understanding the stress history and general properties of construction soils. Estimation of the plasticity index (LL-PL) is important for classifying soils, especially in highly expansive clays.
Parameters
|
Model
|
Electrical drive
|
|
Resolution
|
0.1mm
|
|
Measuring nonlinear error
|
better than 2%
|
|
Conical angle
|
30 ° ± 0.2 °
|
|
Dish drop frequency
|
120hits/min (allowable error 15%)
|
Application
