Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
L:2246*W:1197*H:3 mm
-
Panel Efficiency:
-
19.16%
-
Type:
-
Flexible PV module
-
Solar Cell:
-
Monocrystalline sillicon cell
-
Application Class:
-
Class A
-
Cell Size:
-
182*91
-
Weight:
-
6.3kg
-
Backsheet:
-
White PV Backsheet
-
J-Box:
-
IP67
-
Output cables:
-
4mm^2
-
Connector:
-
MC4 compatible
-
Operating Temperature:
-
-40 degree to 85 degree
Quick Details
-
Cell size:
-
182mmx91mm
-
Brand Name:
-
PURE
-
Model Number:
-
PURES-515-F8MA
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
L:2246*W:1197*H:3 mm
-
Panel Efficiency:
-
19.16%
-
Type:
-
Flexible PV module
-
Solar Cell:
-
Monocrystalline sillicon cell
-
Application Class:
-
Class A
-
Cell Size:
-
182*91
-
Weight:
-
6.3kg
-
Backsheet:
-
White PV Backsheet
-
J-Box:
-
IP67
-
Output cables:
-
4mm^2
-
Connector:
-
MC4 compatible
-
Operating Temperature:
-
-40 degree to 85 degree
|
ITEM
|
|
PURES-515-F8MA
|
PURES-520-F8MA
|
PURES-525-F8MA
|
||||
|
Maximum Power (Pmax )
|
|
515W
|
520W
|
525W
|
||||
|
Maximum Power Voltage (Vmp)
|
|
40.2V
|
40.3V
|
40.4V
|
||||
|
Maximum Power Current(Imp )
|
|
12.85A
|
12.94A
|
13.03A
|
||||
|
Open- circuit Voltage (Voc)
|
|
48.3V
|
48.4V
|
48.5V
|
||||
|
Short-circuit Current（Lsc）
|
|
13.48A
|
13.56A
|
13.67A
|
||||
|
Module Efficiency（%）
|
|
19.16%
|
19.34%
|
19.53%
|
||||
|
Operating Temperature
|
|
|
-40 ℃ to 85 ℃
|
|
||||
|
Maximum System Voltage
|
|
|
1500VDC
|
|
||||
|
Maximum Series Fuse Rating
|
|
|
25 A
|
|
||||
|
Application Class
|
|
|
Class A
|
|
||||
|
Power Tolerance
|
|
|
0~+5 W
|
|
||||
|
STC:Irradiance 1000W/m² , module temperature 25℃ , AM=1.5
|
|
|
|
|
||||
