Product specification:
|
1.Product name:
|
2cm Dynamic Loudspeaker 0.5W-1W Mini 8 Ohm Thin Plastic Shell 20mm Inner Magnetic Manufacture 20mm Inner Magnetic Plastic Shell
|
|
2.Product model No.
|
RB-20008G-65AR-C1
|
|
3.Size:
|
D:20mm, H:5.2 +-0.3mm
|
|
4.Impedance:
|
8 ohm
|
|
5.Power rating:
|
1.0w-1.2w
|
|
6.FO:
|
85+-20%Hz
|
|
7.SPL:
|
99+-3dB/1.0Watt 0.1Meter. At 1000,1200,1500,2000 HZ.1v
|
|
8.
Frequency
Range:
|
FO~20,000HZ
|
|
9.Distortion:
|
10% maximum at 1500HZ.1.0w.
|
|
10.Abnormal sound test:
|
must be normal tested by 2.83 volts.Sine wave for 50~5kHZ
|
|
11.Operating Temperature:
|
-20
degree
to 55 degree
|
|
12.Storage Temperature:
|
-25
degree
to 65
degree
|
Drawing 2D file:
Product curve:
|
|
