- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
KC-EU-12V 0.5A
-
Model type:
-
EU Adapter 5V 9V 12V 0.5A 1A 2A
-
input:
-
110V-240V
-
output:
-
5v-12v /0.5A 1A.2A.3A
-
application:
-
set-top box / CCTV/ LED light
-
Other plug type:
-
Euro type,UK type ,SAA type
-
dc plug:
-
DC4.0*1.7/5.5*2.1
-
Ceritificate:
-
CE,SAA ,ROHS
-
warranty:
-
1 years
-
Cable length:
-
1.2m
-
Color:
-
Black/White
Quick Details
-
Output Type:
-
AC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KUNCAN
-
Model Number:
-
KC-EU-12V 0.5A
-
Model type:
-
EU Adapter 5V 9V 12V 0.5A 1A 2A
-
input:
-
110V-240V
-
output:
-
5v-12v /0.5A 1A.2A.3A
-
application:
-
set-top box / CCTV/ LED light
-
Other plug type:
-
Euro type,UK type ,SAA type
-
dc plug:
-
DC4.0*1.7/5.5*2.1
-
Ceritificate:
-
CE,SAA ,ROHS
-
warranty:
-
1 years
-
Cable length:
-
1.2m
-
Color:
-
Black/White
EU Power Supply Wall Adapter AC To DC 2.1MM 2.5MM Male Connector 12V 0.5A 1A 1.5A
|
INPUT/OUTPUT SPECIFICATIONS: |
|
|
Input Voltage: |
AC 100V-240V,50/60Hz |
|
Range Voltage: |
AC 90V-264V,47/63Hz |
|
Output Power: |
12W |
|
Output Voltage: |
3V-12V |
|
Output Current: |
0.5A-3A |
|
Over Current Protection: |
120% Min |
|
Over Voltage Protection: |
150% Min |
|
Short Protection: |
Auto Recovery |
|
Load Regulation: |
±5% |
|
GENERAL SPECIFICATIONS: |
|
|
Operating Temperature: |
0 ~ 40°C |
|
Operating Relative Humidity: |
5 ~ 95%RH |
|
Storage Temperature: |
-20 ~ 85 °C |
|
Withstanding Voltage: |
AC 3000V/Min |
|
|
(between Input & Output),10mA(Max.) |
|
Insulation Resistance: |
DC500V 100MΩ(Min.) |
|
|
(between Input & Output) |
|
Efficiency: |
70% Min |
|
size: |
52*41*25mm(L*W*H) |
|
SAFETY: |
CE |
