Quick Details
-
Place of Origin:
-
Tianjin
-
Brand Name:
-
Hitrees
-
Dimension(L*W*H):
-
3150mm*2100mm*1950mm
-
Weight:
-
3000 KG
-
Product name:
-
Horizontal Plate Freezer PF-H-600
-
Application:
-
Quick Freezing
-
Capacity:
-
600kg/batch
-
Frozen products:
-
Seafood Vegetables
-
Material:
-
stainless steel
-
Refrigerant:
-
R404a
-
Feature:
-
Easy to operate
Quick Details
-
Voltage:
-
customized
-
Power:
-
customized
-
Cooling Capacity:
-
600 kg/Batch
-
Place of Origin:
-
Tianjin
-
Brand Name:
-
Hitrees
-
Dimension(L*W*H):
-
3150mm*2100mm*1950mm
-
Weight:
-
3000 KG
-
Product name:
-
Horizontal Plate Freezer PF-H-600
-
Application:
-
Quick Freezing
-
Capacity:
-
600kg/batch
-
Frozen products:
-
Seafood Vegetables
-
Material:
-
stainless steel
-
Refrigerant:
-
R404a
-
Feature:
-
Easy to operate
Product Overview
Horizontal Plate Freezer
Hydraulic contact plate freezer can quickly freeze products by moving up and down the inside aluminum plates.
Products contact with two plates and realize heat exchange.
Refrigeration system can be equipped as per different requirements of users.
It is suitable for freezing food in block on land or fishing vessel,Such as fish fillet,surimi,shrimp,shellfish,etc.
Products contact with two plates and realize heat exchange.
Refrigeration system can be equipped as per different requirements of users.
It is suitable for freezing food in block on land or fishing vessel,Such as fish fillet,surimi,shrimp,shellfish,etc.
PRODUCT SPECIFICATIONS
|
Model
|
Freezing capacity
(kg/h) |
Plate
no. |
Plate size
|
Tier pitch
(mm) |
Overall dimension
(mm) |
|
PF-420
|
420
|
8
|
1250×1260
|
55~100
|
2300×1560×2260
|
|
PF-900
|
900
|
10
|
2000×1260
|
55~105
|
4300×1900×2900
|
|
PF-1100
|
1100
|
12
|
2000×1260
|
55~100
|
4300×1900×2900
|
|
PF-1210
|
1210
|
12
|
1700×1459
|
55~100
|
4300×1900×2900
|
|
PF-1300
|
1300
|
14
|
2000×1260
|
55~105
|
4300×1900×3250
|
Details
Freezing Plate
The freezing plate is a plate evaporator, ensuring uniform and smooth flowing of refrigerant, making the surface temperature of the plate uniform and consistent and realizing high heat transfer efficiency.
Good Insulation Performance
The warehouse board uses double-sided stainless steel structure, which has good heat preservation and energy saving.
Structure drawing
Product packaging
