Quick Details
-
EINECS No.:
-
refer to MSDS
-
Place of Origin:
-
China
-
Brand Name:
-
EPHAHS
-
Model Number:
-
E8016
-
Type:
-
Two Component Epoxy Encapsulation Sealant
-
Mixing Ratio:
-
2:1
-
Color:
-
Transparent
-
Appearance:
-
liquid
-
Shelf life:
-
12 Months
-
Main Material:
-
Epoxy Epoxy Adhesive
-
Product name:
-
Two Component Epoxy Potting Adhesive
-
Application:
-
Potting & Encapsulation
-
Application range:
-
hard light bar, display module, photoelectric sensor, etc.
-
Function:
-
encapsulation protection
-
Package:
-
Part A 10kg/ barrel Part B 5kg/ pot
Quick Details
-
CAS No.:
-
refer to MSDS
-
Other Names:
-
pouring sealant, electronic sealant
-
MF:
-
refer to MSDS
-
EINECS No.:
-
refer to MSDS
-
Place of Origin:
-
China
-
Brand Name:
-
EPHAHS
-
Model Number:
-
E8016
-
Type:
-
Two Component Epoxy Encapsulation Sealant
-
Mixing Ratio:
-
2:1
-
Color:
-
Transparent
-
Appearance:
-
liquid
-
Shelf life:
-
12 Months
-
Main Material:
-
Epoxy Epoxy Adhesive
-
Product name:
-
Two Component Epoxy Potting Adhesive
-
Application:
-
Potting & Encapsulation
-
Application range:
-
hard light bar, display module, photoelectric sensor, etc.
-
Function:
-
encapsulation protection
-
Package:
-
Part A 10kg/ barrel Part B 5kg/ pot
Product Description
E8016 Two component potting sealant transparent
epoxy
pouring glue for
electronic
encapsulation
|
ITEM NO
|
APPLICATION
|
PERFORMANCE CHARACTERISTICS
|
|
8016 Transparent Epoxy Potting Sealant
|
Suitable for hard light bar, display module, photoelectric sensor, intelligent water meter and other photoelectric display devices
and products |
Description
E8016 series transparent epoxy potting sealant is a room temperature / heated to curing epoxy resin. This two-component epoxy sealant is designed to protect electronic products that require high strength or confidentiality. The solidified adhesive has the following characteristics: 1, Transparent color epoxy potting material 2, Resistance to moisture, dirt, and other atmospheric components 3, High strength, excellent adhesion, anti - cracking and toughness 4, With a secret operation, no solvent, no curing by-products 5, Stable mechanical and electrical properties between -45 and 90℃ |
Specification
OPERATION PROCESS
Take out the two components A and B in proportion, stir
and mix evenly, vacuum to remove bubbles, and pour
them onto the product to be potted during the operation
period. If the potting product is too large, it is recommended to poach it in several times, and then solidify it according to (60℃/90min or 25℃/24hr).
and mix evenly, vacuum to remove bubbles, and pour
them onto the product to be potted during the operation
period. If the potting product is too large, it is recommended to poach it in several times, and then solidify it according to (60℃/90min or 25℃/24hr).
PRECAUTIONS FOR OPERATION
1、 Please stir well before taking, A, B should be carefully
sealed after taking.
2、 When stirring, attention should be paid to the same
direction of stirring, otherwise too many bubbles will be mixed; Container frame and bottom of the glue should also be stirred evenly, otherwise there will be uneven mixing caused by local solidification phenomenon.
3、 Pouring onto the product and then vacuumizing to
remove bubbles can improve the comprehensive properties of the cured product.
4、 Too low temperature will lead to slow curing speed, it
is recommended to heat curing; The sealing thickness is more than 2cm and cannot be cured directly at 100℃, so as to avoid explosion.
5、 This glue curing process is exothermic reaction, and
the amount of glue will affect the length of the operation time, so the operation time under the amount of 100g glue is only a reference time.
sealed after taking.
2、 When stirring, attention should be paid to the same
direction of stirring, otherwise too many bubbles will be mixed; Container frame and bottom of the glue should also be stirred evenly, otherwise there will be uneven mixing caused by local solidification phenomenon.
3、 Pouring onto the product and then vacuumizing to
remove bubbles can improve the comprehensive properties of the cured product.
4、 Too low temperature will lead to slow curing speed, it
is recommended to heat curing; The sealing thickness is more than 2cm and cannot be cured directly at 100℃, so as to avoid explosion.
5、 This glue curing process is exothermic reaction, and
the amount of glue will affect the length of the operation time, so the operation time under the amount of 100g glue is only a reference time.
|
Item/ Method
|
E8016
|
E8016（2#）
|
EP8016（3#）
|
EP 8016（7#）
|
|
Appearance, Visual inspection, Mixed
|
Colorless and
transparent |
Translucent white
|
Frosted white
|
Colorless and
transparent |
|
Density, g/cm3
25℃ A |
1.12±0.05
|
1.12±0.05
|
1.12±0.05
|
1.14±0.05
|
|
Density, g/cm3
25℃ B |
1.02±0.05
|
1.02±0.05
|
1.02±0.05
|
1.02±0.05
|
|
Density, g/cm3
25℃ Mixed |
1.08±0.05
|
1.08±0.05
|
1.08±0.05
|
1.08±0.05
|
|
Viscosity, cps
25℃ A |
440±50
|
440±50
|
600±150
|
11,000-15,000
|
|
Viscosity, cps
25℃ B |
100±20
|
100±20
|
100±20
|
100±20
|
|
Viscosity, cps
25℃ Mixed |
300-500
|
300-500
|
500-900
|
900-1200
|
|
Operation time, min,25℃
|
60±10
|
60±10
|
60±15
|
40±10
|
|
Curing time, ℃/hr
|
80/2
25/24 |
80/2
25/24 |
80/2
25/24 |
80/2
25/24 |
|
Hardness ,Shore-D
|
D 75
|
D 75
|
D 80
|
D 80
|
|
Volume resistivity,（DC500V）Ω· cm
|
1.2×1015
|
1.2×1015
|
1.2×1015
|
1.2×1015
|
|
Coefficient of expansion, μm/（m，℃）
|
65
|
65
|
65
|
65
|
|
Dielectric constant,1.2MHz,25℃
|
3.53
|
3.53
|
3.53
|
3.53
|
|
Water absorption rate, 24h，25℃，%
|
<0.1
|
<0.1
|
<0.1
|
<0.1
|
|
Dielectric strength, kV/mm（25℃）
|
>20
|
>20
|
>20
|
>20
|
|
Thermal conductivity，W/K.T
|
0.27
|
0.27
|
0.27
|
0.27
|
|
Loss factor, （1MHz）(25℃)
|
0.014
|
0.014
|
0.014
|
0.014
|
Packing & Delivery
|
ITEM NO
|
COMPOSITION
|
PACKING
|
|
8016 Transparent epoxy potting
|
Part A
|
10kg/ pot
|
|
|
Part B
|
5kg/ pot
|
STORAGE AND TRANSPORTATION
1, Dark, heat, sealed.
2, The storage period at 25 ℃ is 12 months. Exceed the storage period, please first sample the test.
PRECAUTION
1, Away from children.
2, Recommended in a well-ventilated place to use.
3, If accidentally stained on the skin, to be immediately washed with soap and water.
4, If accidentally touched the eyes, should immediately rinse with water for a long time, while eyes wide open. If the stimulus is sustained, medical treatment is required.
1, Dark, heat, sealed.
2, The storage period at 25 ℃ is 12 months. Exceed the storage period, please first sample the test.
PRECAUTION
1, Away from children.
2, Recommended in a well-ventilated place to use.
3, If accidentally stained on the skin, to be immediately washed with soap and water.
4, If accidentally touched the eyes, should immediately rinse with water for a long time, while eyes wide open. If the stimulus is sustained, medical treatment is required.
