Quick Details
-
Power:
-
1.3kw, AC
-
Min. Lifting Height:
-
1m, 1.5m, 2m, 2.5m, 3m, 3.5m, 4m, 4.5m, 5m, 6m, 9m, 12m, Customized
-
Table Size:
-
1.43m(L)1m(depth)
-
Overall Dimensions:
-
Customized
-
Weight:
-
350 kg
-
Load Capacity:
-
250kg/customized
-
Color:
-
Customers' Requirements
-
Lifting height:
-
1-12m/Customized
-
Operation way:
-
Remote control/Panel/Column
-
Voltage:
-
110v 220v 240v 380v Optional
-
Pump Station:
-
noiseless
-
self-locking and interlocking:
-
Equipped
-
Hydraulic Oil:
-
32#/46#
-
Lifting speed:
-
4-8m/min
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Cathaylift
-
Power:
-
1.3kw, AC
-
Min. Lifting Height:
-
1m, 1.5m, 2m, 2.5m, 3m, 3.5m, 4m, 4.5m, 5m, 6m, 9m, 12m, Customized
-
Table Size:
-
1.43m(L)1m(depth)
-
Overall Dimensions:
-
Customized
-
Weight:
-
350 kg
-
Load Capacity:
-
250kg/customized
-
Color:
-
Customers' Requirements
-
Lifting height:
-
1-12m/Customized
-
Operation way:
-
Remote control/Panel/Column
-
Voltage:
-
110v 220v 240v 380v Optional
-
Pump Station:
-
noiseless
-
self-locking and interlocking:
-
Equipped
-
Hydraulic Oil:
-
32#/46#
-
Lifting speed:
-
4-8m/min
CE ISO battery powered stair elevator warehouse scissor lift platform for wheelchair
OEM&ODM&OBM
A hydraulic wheelchair lift is a device that is designed to provide vertical transportation for passengers in wheelchairs. It is a type of lift that is operated using hydraulic power and can be installed in both indoor and outdoor environments. The hydraulic wheelchair lift has a maximum lifting height of 15m, making it suitable for use in a range of different settings. It has a standard load capacity of 250kg, although it can be customized to suit the specific needs of different users. It is designed to be highly safe and easy to install, with a small footprint that does not require a machine pit. This makes it a highly versatile and convenient option for those looking to provide wheelchair access in a range of different environments.
|
Model Type |
HL10 |
HL15 |
HL20 |
HL25 |
HL30 |
HL35 |
HL40 |
HL50 |
HL60 |
|
Max. Platform Height |
1000mm |
1500mm |
2000mm |
2500mm |
3000mm |
3500mm |
4000mm |
5000mm |
6000mm |
|
Load Capacity (kg) |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
250kg |
|
N.W/G.W (kg) |
350/450 |
450/550 |
550/700 |
700/850 |
780/900 |
850/1000 |
880/1050 |
1000/1200 |
1100/1300 |
|
Machine Size(mm) |
2000*1430 *1300 |
2500*1430 *1300 |
3000*1430 *1000 |
3500*1430 *1000 |
4000*1430 *1000 |
4600*1430 *1000 |
5100*1430 *1000 |
6100*1430 *1000 |
7100*1430 *1000 |
