- Product Details
- {{item.text}}
Quick Details
-
Max Sewing Thickness:
-
800G/M2
-
Voltage:
-
380V
-
Power:
-
18KW
-
Dimension(L*W*H):
-
8500*3000*2300mm
-
Weight:
-
3000KG
-
Warranty:
-
One year
-
Usage:
-
seaming with no threads and needles
-
Advantage:
-
Ultrasonic control box with strong and stable power
-
Application:
-
Comforter Quilt Blanket Mattress
-
Certification:
-
CE
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
GAINLY
-
Max Sewing Speed:
-
0-20m/min
-
Max Sewing Thickness:
-
800G/M2
-
Voltage:
-
380V
-
Power:
-
18KW
-
Dimension(L*W*H):
-
8500*3000*2300mm
-
Weight:
-
3000KG
-
Warranty:
-
One year
-
Usage:
-
seaming with no threads and needles
-
Advantage:
-
Ultrasonic control box with strong and stable power
-
Application:
-
Comforter Quilt Blanket Mattress
-
Certification:
-
CE
Product Description
Specification
Feature:
*Working with no needles replacing the sewing threads. Patterns can be changed freely... Working effective width of the fabric: 1000--3000mm *High speed and high productivity, strong welding strenth, stable quality *Different rollers and patterns can be designed according to different material and different products requirement. *Humanity control design , easy to operate and understand.
Structure of machine
1) Fabric feeding rack
2) Pattern press compund machine
3) Ultrasonic control cabinet
4) End fabric rolling device
Function: molding,welding,sealing,bonding, embossing, bronzing, etc. Suitable material : composite material,thermoplastic film and plastics slice, such as chemical fibrous cloth, nylon cloth, knitting cloth, non spin cloth, gush glue cotton, PE paper, PE,PVC,ABS, and so on. Application: Lace clothing, tablecloth, chair cover, bedspread, pillowcase, quilt cover,curtain, mattress, bedsheet,etc.
|
Model
|
Power Supply
|
Effective Width
|
Machine Size
|
N.W
|
|
JT-1000-S
|
7kw 380v 3phase (220v)
|
1000mm
|
5*1.5*1.8m
|
1000KG
|
|
JT-1500-S
|
7kw 380v 3phase (220v)
|
1500mm
|
5*2*1.8m
|
1500KG
|
|
JT-1800-S
|
8kw 380v 3phase (220v)
|
1800mm
|
5*2.3*1.8m
|
1800KG
|
|
JT-2300-S
|
8kw 380v 3phase (220v)
|
2300mm
|
5*2.8*1.8m
|
2300KG
|
|
JT-2600-S
|
8kw 380v 3phase (220v)
|
2600mm
|
5*3*1.8m
|
2500KG
|
|
JT-2800-S
|
9kw 380v 3phase (220v)
|
2800mm
|
5*3.2*1.8m
|
2700KG
|
|
JT-3000-S
|
9kw 380v 3phase (220v)
|
3000mm
|
5*3.5*1.8m
|
3000KG
|
Support for customization of
Slitting Cutter and Cross Cutter
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Changzhou Futan Machinery Co., Ltd.,
is China’s first factory specializes in producing ultrasonic equipment and pleating machines.
Its origin can be tracked back to 2003,
Our company is in full compliance with ISO9001 management system standard, and is well staffed with experienced and skilled personnel in respect of production, operation, research and development, management and service respectively. Besides maintaining good and close technical cooperation with many domestic colleges and universities, our company has been introducing advanced equipment and other items from abroad. In our plant, we have ultrasonic lace machine, ultrasonic sewing machine, ultrasonic sealing machine, ultrasonic quilting machine, ultrasonic welding machine, ultrasonic cutting machine,ultrasonic slitting machine, face mask machine, nonwoven bag making machine, shoe cover making machine, cap making machine and pleating machine,fabric pleating machine,automatic fabric pleating machine, multifunction fabric pleating machine,computerized pleating machine, computer controlled pleating machine of more than 40 types in 8 series. Our products are available in Singapore, India, Russia, Vietnam, Egypt, Bengal, Brazil, Turkey, Mexico, America, Spain, Argentina, Ukraine, Italy and Poland, etc. We enjoy a good reputation at home and abroad,Ultrasonic equipment for various special purposes in different industries is available in our plant.
Sticking to the goal of "manufacturing high quality products, offering reasonable pricing and good services", we have been
striving to satisfy all our customers’ needs by reliable products and satisfactory after-sales services.
Our company is in full compliance with ISO9001 management system standard, and is well staffed with experienced and skilled personnel in respect of production, operation, research and development, management and service respectively. Besides maintaining good and close technical cooperation with many domestic colleges and universities, our company has been introducing advanced equipment and other items from abroad. In our plant, we have ultrasonic lace machine, ultrasonic sewing machine, ultrasonic sealing machine, ultrasonic quilting machine, ultrasonic welding machine, ultrasonic cutting machine,ultrasonic slitting machine, face mask machine, nonwoven bag making machine, shoe cover making machine, cap making machine and pleating machine,fabric pleating machine,automatic fabric pleating machine, multifunction fabric pleating machine,computerized pleating machine, computer controlled pleating machine of more than 40 types in 8 series. Our products are available in Singapore, India, Russia, Vietnam, Egypt, Bengal, Brazil, Turkey, Mexico, America, Spain, Argentina, Ukraine, Italy and Poland, etc. We enjoy a good reputation at home and abroad,Ultrasonic equipment for various special purposes in different industries is available in our plant.
Sticking to the goal of "manufacturing high quality products, offering reasonable pricing and good services", we have been
striving to satisfy all our customers’ needs by reliable products and satisfactory after-sales services.
