Quick Details
-
Warranty:
-
30 years linear warranty
-
Brand Name:
-
Canadian
-
Model Number:
-
CS6W-560-580TB-AG
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2278*1134*30mm
-
Module:
-
TopCon N type solar panel
-
Weight (kg):
-
32.3kg
-
Application:
-
Solar power system
-
solar cells:
-
144 [2 X (12 X 6) ]
-
Junction Box:
-
IP68, 3 bypass diodes
-
Connector:
-
T6 or MC4-EVO2 or MC4-EVO2A
-
Packaging Configuration:
-
35 Per Pallet
-
Cables:
-
4 mm2
-
Certificate:
-
TUV / CE
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
Half Cell, Bifacial, N-TYPE, TOPCON, BIPV
-
Panel Efficiency:
-
22.6%
-
Warranty:
-
30 years linear warranty
-
Brand Name:
-
Canadian
-
Model Number:
-
CS6W-560-580TB-AG
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2278*1134*30mm
-
Module:
-
TopCon N type solar panel
-
Weight (kg):
-
32.3kg
-
Application:
-
Solar power system
-
solar cells:
-
144 [2 X (12 X 6) ]
-
Junction Box:
-
IP68, 3 bypass diodes
-
Connector:
-
T6 or MC4-EVO2 or MC4-EVO2A
-
Packaging Configuration:
-
35 Per Pallet
-
Cables:
-
4 mm2
-
Certificate:
-
TUV / CE
Parameter
|
MECHANICAL SPECIFICATION
|
|
|
|
|||
|
Format
|
2278*1134*30mm
|
|
|
|||
|
Weight
|
32.3kg±5%
|
|
|
|||
|
Cell
|
TopCon N-Type cell
|
|
|
|||
|
Junction Box
|
IP68, 3 bypass diodes
|
|
|
|||
|
Connector
|
T6 or MC4 or MC4-EVO2 or MC4-EVO2A
|
|
|
|||
|
CS6W
|
570TB-AG
|
575TB-AG
|
580TB-AG
|
|
Nominal Max. Power (Pmax)
|
570W
|
575W
|
580W
|
|
Opt. Operating Voltage (Vmp)
|
42.7V
|
42.9V
|
43.1V
|
|
Opt. Operating Current (Imp)
|
13.35A
|
13.41A
|
13.46A
|
|
Open Circuit Voltage (Voc)
|
51.8V
|
52.0V
|
52.2V
|
|
Short Circuit Current (Isc)
|
13.81A
|
13.88A
|
13.93A
|
|
Module Efficiency
|
22.1%
|
22.3%
|
22.5%
|
