- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
48V
-
Power Supply:
-
lithium battery
-
Braking System:
-
Disc Brake
-
Battery Capacity:
-
10 AH
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PASEBIKE
-
Model Number:
-
EB05
-
Range per Power:
-
35 - 50 km
-
Charging Time:
-
4~6 hours
-
Product name:
-
EB05
-
Battery:
-
48V 10Ah Li-ion battery (10.4/11.6/12/12.8Ah optional)
-
Motor Power:
-
48V/500W brushless(250W/350W/750W/1000W optional)
-
Brake:
-
Mechanical disc-brake (Hydraulic brake optional)
-
Tire:
-
20"*4.0 pneumatic snow tire black Chaoyang
-
Frame:
-
Alloy aluminum
-
Display:
-
5-lever LCD display with phone charge port
-
PAS:
-
Pedal assisted system & throttle Grip
-
Fork:
-
Aluminum suspension lockout fork
-
Controller:
-
1:1 intelligent pedal assistant system
Quick Details
-
Gears:
-
7 Speed
-
Frame Material:
-
Aluminum Alloy
-
Wheel Size:
-
20"
-
Voltage:
-
48V
-
Power Supply:
-
lithium battery
-
Braking System:
-
Disc Brake
-
Battery Capacity:
-
10 AH
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PASEBIKE
-
Model Number:
-
EB05
-
Range per Power:
-
35 - 50 km
-
Charging Time:
-
4~6 hours
-
Product name:
-
EB05
-
Battery:
-
48V 10Ah Li-ion battery (10.4/11.6/12/12.8Ah optional)
-
Motor Power:
-
48V/500W brushless(250W/350W/750W/1000W optional)
-
Brake:
-
Mechanical disc-brake (Hydraulic brake optional)
-
Tire:
-
20"*4.0 pneumatic snow tire black Chaoyang
-
Frame:
-
Alloy aluminum
-
Display:
-
5-lever LCD display with phone charge port
-
PAS:
-
Pedal assisted system & throttle Grip
-
Fork:
-
Aluminum suspension lockout fork
-
Controller:
-
1:1 intelligent pedal assistant system
| ELECTRIC SYSTEM | MAIN COMPONENT | ||
| Motor | 48V/500W brushless | Frame | Alloy aluminum |
| (250W/350W/750W/1000W optional) | Fork | Aluminum suspension lockout fork | |
| Battery | 48V 10Ah Li-ion battery (10.4/11.6/12/12.8Ah optional) | Derailleur | Shimano 7 speed |
| with electric protection circuit, hidden battery, removable | Cassette | Shimano 7speed | |
| Charger | 100~240V, 50-60Hz, smart fast charger | Brake(F/R) | Mechanical disc-brake (Hydraulic brake optional) |
| 54.6V-2A | Brake Lever | Alloy, power cut when braking | |
| Charge Time | 4-6 hours | Tire | 20"*4.0 pneumatic snow tire black Chaoyang |
| Display | 5-lever LCD display with phone charge port | Rim | Alloy or spoke wheel both available |
| Horn | Available | Grip |
L: Comfort grip with ergonomic shape
R: Twist throttle(thumb shifer optional) |
| Operation | Pedal assisted system ( torque sensor optional) | Handle Bar | Alloy aluminum XieJin |
| PAS | Pedal assisted system & throttle Grip | Handle Post | Adjustable folding handle post XieJin |
| Controller | 1:1 intelligent pedal assistant system | Saddle | Soft comfortable |
| Low noise & durable | Seatpost | Alloy adjustable aluminum XieJin | |
| Light(F) | LED front light (Rear light optional) | Chainwheel | 52T,with alloy crank, Prowheel |
| Integrated Cable | Available, convenient to replace parts | Chain | Rust-resistant chain KMC |
| PERFORMANCE | Pedal | Plastic with reflector, foldable (Aluminum pedal optional) | |
| Climbing ability | 15° | Kickstand | Alloy aluminum thick model |
| Max Speed | 25-40km/h based on customers' requirement | Fender (F & R) | Painted steel |
| Range | 45-50km by PAS, 35-40km by only electric | Rear Rack | Alloy aluminum optional |
| Max Load | 120Kg | Color | Black, blue, red or other required colors (liquid painting ) |
| PACKING & DELIVERY | OTHERS | ||
| N.W/G.W/set | 27kg /31.5kg | MOQ | 10 pcs ( less than 10 pcs will be charged an extra 100 USD ) the price can be negotiated for order qty more than a 20GP |
| Unfolding/Folding Size/set | 1800*635*1020(mm) 1160*580*850(mm) | ||
| Carton Size/set | 1450*280*660(mm) | OEM/ODM | Customized logo, color, specs, CTN are acceptable |
| Container Qty | 90sets/20GP, 175sets/40GP, 220sets/40HQ | ||
| Delivery Time | Sample: 7-15 days, mass production: 30-45 days | ||
