Quick Details
-
Panel Dimensions:
-
528*350*45mm(fold) / 1650*528*5mm( unfold)
-
Panel Efficiency:
-
22%
-
Peak Power(Pmax):
-
60/100Wp
-
Operating Voltage(Vmp):
-
18V
-
Working Current(Imp):
-
3.33/5.55A
-
Open Circuit Voltage(Voc):
-
21V
-
Short Circuit Current(Isc):
-
3.67/6.11A
-
Temperature Range:
-
-40℃~+70℃
-
Output Connector:
-
DC5.5*2.1,USB
-
Net Weight:
-
3.1/4.5Kg
-
Certificate:
-
CE/ISO/TUV/CQC, CE/ISO/TUV/CQC
Quick Details
-
Brand Name:
-
OEM/ODM
-
Model Number:
-
SFZD-20-100B-2
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
528*350*45mm(fold) / 1650*528*5mm( unfold)
-
Panel Efficiency:
-
22%
-
Peak Power(Pmax):
-
60/100Wp
-
Operating Voltage(Vmp):
-
18V
-
Working Current(Imp):
-
3.33/5.55A
-
Open Circuit Voltage(Voc):
-
21V
-
Short Circuit Current(Isc):
-
3.67/6.11A
-
Temperature Range:
-
-40℃~+70℃
-
Output Connector:
-
DC5.5*2.1,USB
-
Net Weight:
-
3.1/4.5Kg
-
Certificate:
-
CE/ISO/TUV/CQC, CE/ISO/TUV/CQC
We have 10 years of customization experience, such as logo, color, pattern, packaging,own design, thank you card, label, etc.
Meet your various needs. Our strength lies low MOQ, 3~7 days sample, fast delivery.
Please contact us to tell your needs.
Product Parameters
| Specification | SFZD-20B | SFZD-30B | SFZD-40B | SFZD-60B | SFZD-80B | SFZD-100B |
| Peak Power(Pmax) | 20Wp | 30Wp | 40Wp | 60Wp | 80Wp | 100Wp |
| Working Voltage(Vmp) | 18V | 18V | 18V | 18V | 18V | 18V |
| Working Current(Imp) | 1.11A | 1.67A | 2.22A | 3.33A | 4.44A | 5.56A |
| Open Circuit Voltage(Voc) | 21V | 21V | 21V | 21V | 21V | 21V |
| Short Circuit Voltage(Isc) | 1.22A | 1.83A | 2.44A | 3.67A | 4.89A | 6.11A |
| Cells | Mono | Mono | Mono | Mono | Mono | Mono |
| Temperature Range | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ | -40℃~+70℃ |
| Connecting Cable | 2*22AWG | 2*22AWG | 2*22AWG | 2*22AWG | 2*22AWG | 2*22AWG |
| Output Connector |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
10-in-1 Connector DC-to-Anderson Cable DC-to-DC Cable DC-to-Clamp for Storage Battery |
| Folding Size | 350*200*35mm | 350*285*35mm | 405*350*35mm | 405*350*40mm | 405*350*45mm | 528*350*45mm |
| Spread Size | 570*350*5mm | 740*350*5mm | 880*405*5mm | 1250*405*5mm | 1610*405*5mm | 1605*528*5mm |
| Net Weight | 0.65Kg | 1.45Kg | 1.9Kg | 2.55Kg | 3.2Kg | 4Kg |
| 10-year Experienced Manufacturer |
Shenzhen Trend Technology Co., Ltd.
Shenzhen Trend Technology Co., Ltd., founded in 2011, is a professional manufacturer oriented to provide our customers high quality products and services. We have cooperated more than 1000 customers in related industries. We can provide OEM & ODM customization services according to our customers' requirements. Looking forward to your cooperation. Thank you!
