SYTA S1023M5 full HD strong signal tuner mstar 7t01 dvb t2 digital tv decoder set top box russia

SYTA S1023M5 full HD strong signal tuner mstar 7t01 dvb t2 digital tv decoder set top box russia

FOB Reference Price: Get Latest Price

≥1 Pieces

US $14

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

RAM:: 2gb

Place of Origin:: Guangdong, China

Brand Name:: OEM/SYTA

Model Number:: S1023M5

Features:: HD-MI

Product Name:: dvb t2 set top box

CPU:: MSTAR-MSD7T01 (128 pin) MIPS 34Kf@600MHz

Memory:: MSD7T01 built-in (32X16Mbit DDR2 Frequency1066)

Flash:: 32M bytes

Demodulator Type:: MSD7T01 built-in Demodulator

TUNER:: Rafael R836

Terrisal Receiver Standard:: DVB-T2/T(EN_302755 V1.3.1/EN 300744)

Input RF Frequency:: VHF177.5MHz~226.5MHz UHF :474MHz~866MHz

Bandwidth:: 7MHz,8MHz

Constellation:: QPSK 16-QAM 64-QAM and 256-QAM

Quick Details

Processor Core:: Quad Core

Support Resolution:: 1920 x 1080

WiFi:: 802.11ac

RAM:: 2gb

Place of Origin:: Guangdong, China

Brand Name:: OEM/SYTA

Model Number:: S1023M5

Features:: HD-MI

Product Name:: dvb t2 set top box

CPU:: MSTAR-MSD7T01 (128 pin) MIPS 34Kf@600MHz

Memory:: MSD7T01 built-in (32X16Mbit DDR2 Frequency1066)

Flash:: 32M bytes

Demodulator Type:: MSD7T01 built-in Demodulator

TUNER:: Rafael R836

Terrisal Receiver Standard:: DVB-T2/T(EN_302755 V1.3.1/EN 300744)

Input RF Frequency:: VHF177.5MHz~226.5MHz UHF :474MHz~866MHz

Bandwidth:: 7MHz,8MHz

Constellation:: QPSK 16-QAM 64-QAM and 256-QAM

SYTA S1023M5 full HD strong signal tuner mstar 7t01 dvb t2 digital tv decoder set top box russia

t2 russia/dvbt2

Product Description

1.MLStandard DVB-T2/ High Definition MPEG4 AVC/H.264 HP@L4,MPEG-2 MP@HL

2.Automatic PAL/NTSC conversion

3.2000 channels TV and Radio programmable

4.The maximum speed of the traffic flow of at least 50 Mbit / sec

5.•Support 3D interface 8 different favorite groups selection

6.Fully support to 7 days Electronic Program Guide(EPG)

7.JPEG BMP GIF support,Flesh tone extension,Black/White extension

8.4/8/16-bit OSD with anti-flickering

9.Channel search in automatic, manual and network search

10.Various channel editing function(favorite,move,lock,skip,delete,rename,find,sort)

11.Parental control for channels

12.Plug and Play installation, with an ease to use Menu System

13.Software upgrades through USB/Cardreader

14.Time set by GMT offset automatic and manual,Summer Time support

15.5 event timers,off/Once/Daily/Weekly/Monthly Mode

16.Subtitle support

17.VBI insertion for Teletext,CC and WSS

18.Automatic save for last channel

19.Support Logic Channel Number(LCN)

20.Active Antenna Power supply control

Characteristics:

CPU: MSTAR-MSD7T01 (128pinos) 34Kf MIPS @ 600 MHz.
Memory: MSTAR-MSD7T01 implant DDR2 32X16Mbit Frequency1066
Flash: 32 M bytes.
Demodulator Type: MSTAR-MSD7T01 implant.
Tuner: Rafael R836.
Demodulation:
Terrestrial Receiver DVB-T2 / T (EN_302755 V1.3.1 / EN 300744).
RF input frequency: 48 ~ 866 MHz.
Bandwidth: 6 MHz, 7 MHz, 8 MHz.
Constellation: QPSK 16-QAM and QAM-QAM.
FEC: 1/2, 3 / 5.2 / 3, 3/4, 4/5, 5/6.
Guard interval: 1/128, 1/32, 1/16, 19/256, 1/8, 19/128, 1/4.
FFT Mode: 2K / 8K / 32K.
Entry level: -83--5dBm.
Software Features:
Fully comply with DVB-T / T2 and H.264, MPEG-4, MPEG-2 standard.
The maximum speed of traffic flow at least 50 Mbit / sec.
It supports 3D interface.
Supports Sleep timer.
Supports teletext / subtitle / muti-language.
EPG function powerful and highly effective.
Auto, 16: 9 pillar box, 16: 9 G Pan Scan, 4: 3 Letter Box, 4: 3 Pan Scan G, 4: 3, 16: 9 widescreen
USB 2.0 for PVR, Timeshift, software update and playback media files.
Video output resolution: 480i / 576i / 480p / 576 p / 720p / 1080i / 1080p.
Video decoder: Compatible with: MPEG-4 part10 / MPEG-2 ISO / IEC 13818.
MPEG-4 Simple / Main / Advanced Profile @ LEVEL3 (10 Mbps).
MPEG-2 main profile # Main level (15 Mbps).
H.264 MP # L3 (10 Mbps). H.264 HP L4.1 (25 Mbps).
Audio decoder: MPEG-1, MPEG-2 (Layer I / II), MP3, AC-3 (Dolby Digital), LC-AAC, WMA
E-AC-3 (Dolby Digital Plus) HE-AAC decoding 5.1 multi-chhannel decoding.
MediaCodec: AVI. MPG ,. DAT ,. VOB ,. Div ,. MOV ,. MKV ,. JPEG ,. TS etc.
Audio: WMA, MP3, AAC (WMA, m4a.).
Photo Codec: JPEG, BMP, PNG.
License: Optional DTS, Dolby Digital, Dolby Digital Plus, RM / RMVB, DivX license.
