Quick Details
-
Model Number:
-
PD-PIR113A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
PDLUX
-
Theory:
-
Moving Induction
-
Output:
-
Switching Transducer
-
Power source:
-
85VAC-265VAC
-
Power frequency:
-
50/60Hz
-
Rated load:
-
2000W/800W/200W
-
Detection range:
-
15m max(wall installation) 13m max(ceiling installation)(24-26℃)
-
Light-control:
-
more than 50LUX(it can be customized to your need)
-
Installation height:
-
2-12m (ceiling installation), 2-3m(wall installation)
-
Detection angle:
-
120/360 degree
-
Time setting:
-
Delay time can be set by the key or remoter
-
Working temperature:
-
-10-+40℃
Quick Details
-
Use:
-
Auto-switch
-
Mounting Type:
-
wall/ceiling mounted
-
Description:
-
Infrared motion sensor
-
Model Number:
-
PD-PIR113A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
PDLUX
-
Theory:
-
Moving Induction
-
Output:
-
Switching Transducer
-
Power source:
-
85VAC-265VAC
-
Power frequency:
-
50/60Hz
-
Rated load:
-
2000W/800W/200W
-
Detection range:
-
15m max(wall installation) 13m max(ceiling installation)(24-26℃)
-
Light-control:
-
more than 50LUX(it can be customized to your need)
-
Installation height:
-
2-12m (ceiling installation), 2-3m(wall installation)
-
Detection angle:
-
120/360 degree
-
Time setting:
-
Delay time can be set by the key or remoter
-
Working temperature:
-
-10-+40℃
Product Description
Specification
|
Power Source
|
85-265V/AC
|
|
Power Frequency
|
50/60Hz
|
|
Rated Load
|
2000W Max.tungsten (265V/AC)
800W Max.fluorescent (265V/AC ) 800W Max.tungsten (85V/AC) 200W Max.fluorescent (85V/AC ) |
|
Time Setting
|
(Delay time can be set by the key or remoter)
3min, 6min, 9min, 12min, 15min, 18min, 21min, 24min, 27min, 30min |
|
Detection Range
|
15m Max(wall installtion)13m Max.(ceiling installtion)(24°C~26°C)
|
|
Detection Angle
|
360° 120°
|
|
Working Temperature
|
-10℃ ~ +40℃
|
|
Working Humidity
|
<93%RH
|
|
Light-control
|
<50LUX (it can be customized to your needs)
|
|
Installation Height
|
2-12m(ceiling installtion)2-3m(wall installtion)
|
|
Detection Motion Speed
|
0.6~1.5m/s
|
Application
