160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3
160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3

160Hp Chinese Bull Dozer Factory Bulldozer D6 D7 D8 D9 Price List ZD160F-3

FOB Reference Price: Get Latest Price
≥1 Pieces
US $75000
≥2 Pieces
US $60000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Place of Origin:
China
Model Number:
ZD160F-3
Product name:
Bulldozer
After Warranty Service:
Video technical support
Local Service Location:
None
After sales Service Provided:
Field installation, commissioning and training

Quick Details

Machine Weight:
3150 KG
Dozing Capacity:
6.6m3
Marketing Type:
Hot Product 2021
Place of Origin:
China
Model Number:
ZD160F-3
Product name:
Bulldozer
After Warranty Service:
Video technical support
Local Service Location:
None
After sales Service Provided:
Field installation, commissioning and training

160Hp Small Dozer And Bulldozer ZD160F-3 With Winch For Sale

CONTACT INFORMATION

Name:Ruben

Whatsapp:008613351280812

CHN/ENG/ESP

Contact me via WhatsApp so we can communicate more conveniently

Looking forward to your message.

Product Description

The power system of ZD160 series bulldozer is equipped with WEICHAI WD10G178E25 turbocharged engine. With fuel consumption reduced by 20%- 25%, the environmentally friendly engine features high reliability, energy-saving performance and less noise. Working together with an advanced driveline, it provides advanced power matching and high rated power. Precise and reliable electronic monitoring system enables operators to know the equipment operation condition in real time.

The ZD160F-3 is a medium-and-low horsepower bulldozer developed on the basis of ZD160-3 bulldozer and with the reference of the advanced technologies at home and abroad, and is widely used in various engineering constructions such as energy, transportation, building, mining, municipal engineering and farmland water conservancy. A variety of working devices can be configured on it to meet the user needs; what’s more, its superior cost performance makes its application range more widely.

The hexahedral steel enclosed cab installed on ZD160F-3 provides wide vision and can be equipped with roll over protection system and air conditioning system (cool/heat) as required by users. The elastic damping device is applied for the cab mounting surrounded by absorbent materials, which, plus the sealing effect of the interior materials, make the noise inside the cab reduced significantly.

Item Unit ZD160F-3
Key    Technical Parameter Blade type - Angle Blade
Working mass kg 17236
Blade capacity m3 4.4
Engine model - WD10G178E25
Rated power/Slewing speed kW/rpm 131
Max. torque N.m/rpm 830/1100
Min. fuel consumption g/kW.h 215
Max. Drawbar pull Kn 152
Ground pressure kPa 59.3
Gradeability° ° 30
Traveling speed of forward km/h 3.8/6.6/10.6
Traveling speed of Reverse km/h 4.9/8.5/13.6
Basic    Technical Parameter Height of cab mm ——
Height of ROPS mm 3200
Ground contact length mm 2430
Height of blade mm 1032
Track center distance mm 1880
Height of grouser mm 65
Track shoe width mm 510
Operating    Range Max. lift height of dozer mm 1110
Max. drop depth mm 545
Max. lift height of ripper mm ——
Max. ripping depth of ripper mm ——
Max. tilt mm ——
