Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
595*515*2mm/1115*515*2mm
-
Panel Efficiency:
-
21.5-23.9%
-
Cell Type:
-
Half Cut Cell
Quick Details
-
Cell size:
-
182mmx182mm
-
Brand Name:
-
sunmaster
-
Model Number:
-
SM50-100W FX
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
595*515*2mm/1115*515*2mm
-
Panel Efficiency:
-
21.5-23.9%
-
Cell Type:
-
Half Cut Cell
Contact us to get the details certification doucments
|
Parameter Name |
Unit |
SMFX-50 |
SMFX-100 |
|
Maximum power ( Pm ) |
W |
50W |
100W |
|
Power Deviation |
W |
0~+5w |
0~+5w |
|
Optimal working voltage ( Vm ) |
V |
18 |
18 |
|
Optimal working current ( lm ) |
A |
3.2 |
5.5 |
|
Open-circuit voltage ( Voc ) |
V |
19.3 |
19.8 |
|
Short-circuit current ( lsc ) |
A |
2.6 |
5.05 |
|
The largest system voltage |
DC1500V(IEC) |
||
|
The largest fuse rated current |
20A |
||
|
Operating temperature range |
-40~+120 ℃ |
||
|
Connector |
MC Compatible |
||
