Quick Details
-
Screen Size:
-
5.52 inch
-
CPU:
-
Quad-Core 1.35GHZ
-
RAM:
-
1 GB
-
SSD:
-
8GB
-
Operation System:
-
Android 7
-
Compatible Devices:
-
Android
-
printer technology:
-
THERMAL
-
Sheet Size:
-
58MM
-
Place of Origin:
-
Guangdong, China
-
Display:
-
5.5 inch TFT IPS LCD resolution 1280*720
-
Dimensions:
-
206mm*84mm*32mm (max 56mm)
-
Input:
-
Chinese/English ,and supports handwriting and soft keyboard
-
WIFI:
-
IEEE 802.11 a/b/g/n ,support dual Band 2.4GHZ and 5GHZ
-
BT:
-
BT 4.0 LE +EDR
-
Smart Card reader:
-
Supports ISO7816 standard
-
Contactless Card reader:
-
Supports 14443A / 14443B
-
Micro SD Card Slot:
-
1 PCS
-
Battery:
-
Li-ion battery, 7.4V /2600mAH
-
Warranty:
-
1 Year
Quick Details
-
Model Number:
-
HCC-Z100
-
Country of Origin:
-
China
-
Brand Name:
-
HCCTG
-
Screen Size:
-
5.52 inch
-
CPU:
-
Quad-Core 1.35GHZ
-
RAM:
-
1 GB
-
SSD:
-
8GB
-
Operation System:
-
Android 7
-
Compatible Devices:
-
Android
-
printer technology:
-
THERMAL
-
Sheet Size:
-
58MM
-
Place of Origin:
-
Guangdong, China
-
Display:
-
5.5 inch TFT IPS LCD resolution 1280*720
-
Dimensions:
-
206mm*84mm*32mm (max 56mm)
-
Input:
-
Chinese/English ,and supports handwriting and soft keyboard
-
WIFI:
-
IEEE 802.11 a/b/g/n ,support dual Band 2.4GHZ and 5GHZ
-
BT:
-
BT 4.0 LE +EDR
-
Smart Card reader:
-
Supports ISO7816 standard
-
Contactless Card reader:
-
Supports 14443A / 14443B
-
Micro SD Card Slot:
-
1 PCS
-
Battery:
-
Li-ion battery, 7.4V /2600mAH
-
Warranty:
-
1 Year
Product Description
|
CPU
|
Quad-Core 1.35GHZ
|
|
LCM
|
5.5 inch TFT IPS LCD resolution 1280*720
|
|
Battery
|
Li-ion battery, 2600mAh 7.4V
|
|
Card Reader
|
NFC & IC & MSR Reader
|
|
Fingerprint
|
Optional
|
|
Barcode Scanner
|
Optional
|
|
Network
|
4G+Wifi+Bluetooth
|
|
Printing
|
58mm Thermal Printer,40mm Paper Roll
|
Product Usage
Product Paramenters
|
Specification
|
|
|
|
|
Basic
Characteristics |
OS
|
Safedroid OS (based on Android 7.0)
|
|
|
|
CPU
|
Quad-Core 1.35GHZ
|
|
|
|
ROM
|
8GB ROM EMMC
|
|
|
|
RAM
|
1G RAM LPDDR3
|
|
|
|
Display
|
5.5 inch TFT IPS LCD resolution 1280*720
|
|
|
|
Panel
|
Ultra-sensitive capacitive touch screen, can work with gloves and wet fingers
|
|
|
|
Dimensions
|
206mm*84mm*32mm (max 56mm)
|
|
|
|
Weight
|
530g(Battery included)
|
|
|
|
Keys
|
3 Physical keys:1 ON/OFF KEY,2 Shortcut keys
3 Virtual keys: Menu, Home, Back |
|
|
|
Input
|
Chinese/English ,and supports handwriting and soft keyboard
|
|
|
Radio Communication
|
WIFI
|
IEEE 802.11 a/b/g/n ,support dual Band 2.4GHZ and 5GHZ
|
|
|
|
BT
|
BT 4.0 LE +EDR
|
|
|
|
4G
|
TD-LTE:Band38, Band39, Band40, Band41
FDD-LTE:Band1,Band3,Band7,Band8,Band20 |
|
|
|
3G
|
UMTS(WCDMA)/HSPA+:Band1,Band8,Band2,Band5
TD-SCDMA:Band34,Band39 |
|
|
|
2G
|
GSM/GPRS/EDGE:850/900/1800/1900MHZ
|
|
|
Card reader
|
Magnetic Card reader
|
Supports ISO7811/7812/7813, and supports triple
track (tracks 1/2/3), bi-directional |
|
|
|
Smart Card reader
|
Supports ISO7816 standard;
AT24C01、AT24C02、AT24C04、AT24C08、AT24C16、AT24C32、AT24C64、AT88SC101、AT88SC102、AT88SC153、AT88SC1608、SLE4442、SLE4428; |
|
|
|
Contactless Card reader
|
Supports 14443A / 14443B、NFC-F（JIS 6319-4）、NFC-V（ISO 15693）、ISO-DEP（ISO 14443-4）、FeliCa、MIFARE、DESFire
|
|
|
Expansion and peripherals
|
Printer
|
High-Speed Thermal Printer ;
58mm printing paper ; 40mm paper roll; |
|
|
|
Camera
|
5MP camera with LED flash and auto-focus function
|
|
|
|
Satellite Positioning
|
GPS, Supports A-GPS
|
|
|
|
Audio
|
Speaker ,Microphone, Earphone
|
|
|
Interfaces
|
Micro SD Card Slot
|
1 PCS
|
|
|
|
SIM Card Slot
|
2 PCS MICRO SIM
|
|
|
|
PSAM Card Slot
|
2 PCS Conforms to ISO7816 standard
|
|
|
|
USB Port
|
1PCS TYPE C USB
|
|
|
Power
|
Battery
|
Li-ion battery, 7.4V /2600mAH
|
|
|
|
Charging Port
|
Type C USB Port ,5V DC,2A
|
|
|
Environment
|
Operating Temperature
|
-10°C to 50°C
|
|
|
|
Storage Temperature
|
-20°C to 70°C
|
|
|
|
Humidity
|
5% to 95% Relative Humidity, Non-Condensing
|
|
|
Certification
|
Electromagnetic
|
CE, FCC, ROHS
|
|
|
Anti-tamper
|
Without Anti-tamper function
|
|
|
|
Optional
|
Fingerprint
|
Semiconductor capacitance
18mm x 12.8mm imaging area 256 x 360 pixel array Crossmatch FBI certified 508dpi |
|
|
|
Front camera
|
2 Megapixel Fixed Focal Camera
|
|
|
|
Barcode Scanner
|
Honeywell 2D Image Engine, Support 1D and 2D symbologies
|
|
|
|
Positioning
|
GLONASS, Bei-Dou satellite navigation system
|
|
