Quick Details
-
Light Source:
-
LED
-
Product Weight（kg）:
-
0.6
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sanforce
-
Product Name:
-
CE RoHS LED rechargeable emergency light batteries power pack
-
Input Voltage:
-
85V-265V 50/60HZ
-
Charge time:
-
24hrs
-
Warranty:
-
3 Years
-
Emergency Time:
-
3Hrs
-
Emergency Power:
-
9W
-
Output Voltage:
-
50-90V
-
inverter Size:
-
155*40*30mm
-
Metal Case Size:
-
200*100*50mm
-
Battery:
-
Ni-cd Battery
Quick Details
-
Battery Type:
-
Ni-CD
-
Material:
-
metal
-
Usage:
-
emergency lighting
-
Light Source:
-
LED
-
Product Weight（kg）:
-
0.6
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sanforce
-
Product Name:
-
CE RoHS LED rechargeable emergency light batteries power pack
-
Input Voltage:
-
85V-265V 50/60HZ
-
Charge time:
-
24hrs
-
Warranty:
-
3 Years
-
Emergency Time:
-
3Hrs
-
Emergency Power:
-
9W
-
Output Voltage:
-
50-90V
-
inverter Size:
-
155*40*30mm
-
Metal Case Size:
-
200*100*50mm
-
Battery:
-
Ni-cd Battery
Desription
Sanforce Emergency power packs allow the LED fixtures to meet requirement for emergency illumination.
Designed especially for Constant Current type LEDs and circuits. Utilizing DC/DC switcher circuitry. Product is compatible with wide range of LED fixture ideal for LED panel light, LED down light,LED ceiling light and many others with external LED driver and low voltage(15-90V).
| Model No. | LMO103C009P |
| Product Name | CE RoHS LED rechargeable emergency light batteries power pack |
| Battery Type | NiMH, NiCd, Lithium battery |
| Lighting Power | 36W LED panel |
| Emergency Power | 9w |
| Input voltage | AC85~265V, 50/60Hz |
| Battery protection | Yes |
| Operation temperature | -20--70℃ , 65+20% RB |
| Highest Surface Temperature | 50°C |
| Battery Capacity | 12V 2800mAh Rechargeable Nicd battery pack |
| Charging Time | >24h without break |
| Output Voltage in emergency | DC50-90V,100mAh |
| Suitable light source | LED PANEL, DOWN LIGHT, CEILING LIGHT |
| Emergency power level | 25% |
| Emergency duration | 180 minutes |
| Product Weight | 1.8kgs |
| Inverter dimension | 155*40*30mm |
| Outer casing size | 200*100*50mm |
| Note | Custom-Made battery to be configured with different back-up period and different light output levels. |
Desription
Sanforce Emergency power packs allow the LED fixtures to meet requirement for emergency illumination.
Designed especially for Constant Current type LEDs and circuits. Utilizing DC/DC switcher circuitry. Product is compatible with wide range of LED fixture ideal for LED panel light, LED down light,LED ceiling light and many others with external LED driver and low voltage(15-90V).
Advantage
1) Customized solution for inverter and battery, more economical
2) Life cycle for emergency inverter can reach 50,000 hour
3) Battery life can reach 500-800 cycles
4) Charging indicator equipped
5) Test switch to inspect the emergency line at any time.
6)3 years warranty
7)Excellent high temperature endurance
