Quick Details
-
Dimension(L*W*H):
-
4000x1500x3060
-
Power (kW):
-
2.2 kW
-
Weight (KG):
-
1000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Nominal Clamping Force(MN):
-
4.8
-
Hot Plate Specs (mm):
-
1600x1500
-
Hot Plate Pressure Per Unit Area(Mpa):
-
2.0
-
Main motor power(KW):
-
13
-
Inner Girth of Vulcanization Belt(KW):
-
4700
-
Overall Size(LXWXH)mm:
-
4000X1500X3060
-
Configuration:
-
Frame
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUICAI
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
4000x1500x3060
-
Power (kW):
-
2.2 kW
-
Weight (KG):
-
1000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Nominal Clamping Force(MN):
-
4.8
-
Hot Plate Specs (mm):
-
1600x1500
-
Hot Plate Pressure Per Unit Area(Mpa):
-
2.0
-
Main motor power(KW):
-
13
-
Inner Girth of Vulcanization Belt(KW):
-
4700
-
Overall Size(LXWXH)mm:
-
4000X1500X3060
-
Configuration:
-
Frame
Customize OEM/ODM SERVICE
WELCOME TO OUR FACTORY VIST AND NEGOTIATION
vulcanizing track,V-belt and othe ring shape rubber product.
Multi-cylinder configuration make machine be able to work stably and have uniform pressure
Automatic moid forward/backward,or pass in and out material on left and righe;
PLC-controlled,it has stable performance,operators may set and lock processing parameters according to their own need in order to guarantee product quality,production,formation automatic control;
it is able to release the air automatically and air-releasing frequency,air-releasing time and air-releasing distance may be set according to your need;
It is able to replenish pressure loss caused by stock flow;
Unit surface pressure no less than 45kg/cm to ensure the density of tread;
The work tables and the layer number design according to the customer need;
Hydraulic components and electrical equipment imported or of local famous brand,to ensure reliable performance;
Has the auto-alam system,safety and reliability
|
Type |
XLE-
|
XLE-
|
XLE-
|
XLE-
|
XLE-
|
XLE-
|
|
Nominal Clamping Force(MN) |
0.20 |
0.40 |
0.60 |
1.2 |
1.8 |
4.8 |
|
Hot Plate Specs mm |
400x200 |
400x400 |
400x600 |
400x1200 |
800x1100 |
1600x1500 |
|
Hot Plate Pressure Per Unit AreaMpa |
2.5 |
2.5 |
2.5 |
2.5 |
2.0 |
2.0 |
|
Main Motor Power kw |
2.2 |
3 |
3 |
7.5 |
3 |
13 |
|
Inner Girth of Vulcanization Belt (mm) |
960-3500 |
1680-3600 |
1680-3700 |
5000-17000 |
- |
4700 |
|
Overall Size(LxWxH)mm |
3200x1050
|
3200x1050
|
3200x1050
|
3200x1050
|
2400x1100
|
4000x1500
|
|
Product Weight(kg) |
4000 |
4500 |
5000 |
8000 |
14000 |
20000 |
