Here at Shenzhen Yake LED Tech Co., Ltd,
Found in 2009, we have become a pioneer in the LED industry for the development of our double sides led screen, gas station LEDs, taxi top led screen, outdoor LED screen, indoor LED screen, outdoor led modules, indoor led modules. We are proud to offer our customers a comprehensive service, earning us their trust and respect
.
- Product Details
- {{item.text}}
Quick Details
-
Panel Size:
-
320mmx160mm/160mmx160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P10
-
Brand name:
-
Yake
-
Usage:
-
outdoor
-
Tube Chip Color:
-
full color
-
Pixels:
-
P10
-
Module Size:
-
320mmx160mm
-
Driving Method:
-
1/2 scan
-
Pixel size:
-
960mmx960mm
-
Certificate:
-
CE ROHS FCC
-
Warranty:
-
3 Years
-
Life Span:
-
100000 Hours
Quick Details
-
Application:
-
Outdoor
-
Brand Name:
-
Yake
-
Color:
-
Full Color
-
Panel Size:
-
320mmx160mm/160mmx160mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P10
-
Brand name:
-
Yake
-
Usage:
-
outdoor
-
Tube Chip Color:
-
full color
-
Pixels:
-
P10
-
Module Size:
-
320mmx160mm
-
Driving Method:
-
1/2 scan
-
Pixel size:
-
960mmx960mm
-
Certificate:
-
CE ROHS FCC
-
Warranty:
-
3 Years
-
Life Span:
-
100000 Hours
Product Description
10mm Pixel Pitch 320 X 160mm Module PH10 outdoor full color led display
P10 SMD outdoor led module
Size 320mmx160mm
Refresh rate ≥ 1920HZ
1/2 scan
SMD3535 LED diode
IC: MBI5124
P10 SMD outdoor led module
Size 160mmx160mm
Refresh rate ≥ 1920HZ
1/4 scan
DIP346 LED diode
IC: MBI5124
|
P10 Cabinet For Fixed Installation
|
Value
|
|
Size
|
960mmx960mm
|
|
Weight
|
34kg/pc
|
|
IC
|
MBI5124
|
|
Power Consumption
|
250w/800w(average/max)
|
|
Brightness
|
8000nits
|
|
P10 Cabinet For Rental
|
Value
|
|
Size
|
960mmx960mm
|
|
Weight
|
25kg/pc
|
|
Material
|
Diecasting Aluminum
|
|
Control system
|
Linsn/Novastar/Dbstar/Huidu
|
|
Power consumption
|
250w/800w(average/max)
|
Famous Brands Raw Material Selection
1)LED: well-known international brand,with wide viewing angle ,little attenuation ,good heat dissipation, and vivid colors.
2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective
phenomena, such as dark bright, virtual light and so on.
3) Power supply: industrial-strength brand.The power maximum power resere of 20% the space , the range of voltage fluctuation is less 5%, high stability.
4) Connector: Aerial grade brands ensure the stable transmission of power and signal.
5) PCB Board: adopt 4-layer design.
6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person.
The replacement of any cabinet can be done within 50 seconds.
Aging Test pictures
Our Company
Profile.
Package
Factory
Our Service
We have an excellent customer service system with a well-trained, strong and skilled service team to provide customers with a comprehensive pre-sales service, product services and after-sales service.
Our customer service department has more than a dozen highly skilled and experienced technical support engineers, who are all in charge of the technical support of all LED display products we provide all over the world.
We are continuously improving upon our level of service and quality to quickly and effectively meet customer needs and guarantee their benefits and interests.
Service Concept
We believe in taking the initiative, maintaining honesty and trustworthiness, which means we will respond quickly to customer questions and do everything possible to meet customer demands.
Service Content
1. 24-hour hotline service, including counseling and technical guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Warranty service.
7. Engineering technical service.
Warranty Period
Each of our LED display products comes with at least two years warranty and a lifetime maintanance services.
