Quick Details
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1800*1300*1680
-
Weight:
-
1080 KG
-
Marketing Type:
-
Other
-
Press type:
-
Screw Cold Hot Oil Press
-
Process:
-
Phsical Refining
-
After Warranty Service:
-
Technical Support Online
-
Oil rate:
-
Meal Residual: 1%
-
Main market:
-
Ghana
-
Capacity:
-
Large
-
Processing Types:
-
Screw Pressing
-
After-sales Service:
-
Offering Installation
-
Application range:
-
Crude Seed Oil
-
Machine Material:
-
Sstainless Steel
Quick Details
-
Production Capacity:
-
60-700kg/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
BOYUE
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
1800*1300*1680
-
Weight:
-
1080 KG
-
Marketing Type:
-
Other
-
Press type:
-
Screw Cold Hot Oil Press
-
Process:
-
Phsical Refining
-
After Warranty Service:
-
Technical Support Online
-
Oil rate:
-
Meal Residual: 1%
-
Main market:
-
Ghana
-
Capacity:
-
Large
-
Processing Types:
-
Screw Pressing
-
After-sales Service:
-
Offering Installation
-
Application range:
-
Crude Seed Oil
-
Machine Material:
-
Sstainless Steel
Product Description
The screw oil press uses the changes in the volume of the press chamber, the drive of the spiral worm, the resistance of the curve teeth of the press ring, and the squeezing force generated by the squeezing friction between the oil materials to separate the oil from the oily materials. Under the enormous pressure generated in the press chamber, oil is discharged from the gap between the press bars and the oil groove of the press ring.
Recommend Products
6YL-70 TYPE OIL PRESS MACHINE
Model：6YL-70
Power：3kw
Capacity：45-70kg
/h
Weight：320kg
Size：1450x870x1180mm
6YL-100 TYPE OIL PRESS MACHINE
Model：6YL-100
Power：7.5kw
Capacity：150-230kg/h
Weight：1100kg
Size：1800x1200x1500mm
6YL-125 TYPE OIL PRESS MACHINE
Model：6YL-125
Power：15kw
Capacity：300-400kg/h
Weight：1500kg
Size：2300x1300x2200mm
6YL-150 TYPE OIL PRESS MACHINE
Model：6YL-150
Power：26kw
Capacity：500kg/h
Weight：1680kg
Size：2430x1250x2850mm
Product Paramenters
|
Model
|
70
|
100
|
125
|
150
|
|
Screw diameter
|
70mm
|
100mm
|
125mm
|
150mm
|
|
Screw speed
|
52 r/min
|
38 r/min
|
36 r/min
|
35 r/min
|
|
Power
|
3Kw
|
7.5Kw
|
15 kw
|
26 Kw
|
|
Product capacity
|
45-70kg/h
|
150-230 kg/h
|
300-400 kg/h
|
500 kg/h
|
|
Weight
|
320 kg
|
1100 kg
|
1500kg
|
1680 kg
|
|
Dimension（mm）
|
1450x870x
1180
|
1800x1200x
1500
|
2300x1300x
2200
|
2430x1250x
2850
|
