Quick Details
-
Brand Name:
-
Shantui
-
Model Number:
-
SD16R
-
Dimension(Long * Breadth * High):
-
5474*4150*3074mm
-
Product name:
-
SHANTUI SD16R Bulldozer
-
Model & type:
-
Shangchai SC11CB184G2B1/Weichai WD10G178E25
-
Min. fuel consumption:
-
214 g/kW.h
-
Maximum pressure:
-
20.6 MPa
-
Pump type:
-
Gear pump
-
Blade type:
-
R-blade
-
Dozing capacity:
-
8.3 m3
-
Blade width:
-
4150 mm
-
Blade height:
-
1578 mm
-
Maximum drop below ground:
-
485 mm
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Egypt, United States, Philippines, Pakistan, India, Thailand, Japan, Malaysia, South Korea, Sri Lanka, Romania, Ukraine, Kyrgyzstan
-
After-sales Service Provided:
-
Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Free spare parts
Quick Details
-
Machine Weight:
-
17.7ton
-
Dozing Capacity:
-
8.3m3
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Shantui
-
Model Number:
-
SD16R
-
Dimension(Long * Breadth * High):
-
5474*4150*3074mm
-
Product name:
-
SHANTUI SD16R Bulldozer
-
Model & type:
-
Shangchai SC11CB184G2B1/Weichai WD10G178E25
-
Min. fuel consumption:
-
214 g/kW.h
-
Maximum pressure:
-
20.6 MPa
-
Pump type:
-
Gear pump
-
Blade type:
-
R-blade
-
Dozing capacity:
-
8.3 m3
-
Blade width:
-
4150 mm
-
Blade height:
-
1578 mm
-
Maximum drop below ground:
-
485 mm
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Egypt, United States, Philippines, Pakistan, India, Thailand, Japan, Malaysia, South Korea, Sri Lanka, Romania, Ukraine, Kyrgyzstan
-
After-sales Service Provided:
-
Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Free spare parts
China Shantui 160HP SD16R Bulldozer with Ripper
FEATURES
Shantui’s best-seller worldwide, this is a medium-duty workhorse that comes off the factory line in various configurations for specific work environments, e.g., desert, swamp, forest, high altitude, etc. It has a Tier IIIb famous engine for European markets and optional engines for other markets. The SD16 provides high performance with strong reliability, with Shantui’s trademark value.
Specification for SD16R
|
160 HP
specifications: |
Blade Type | Straight-tilt | Angle | R-Blade |
| Min. ground clearance: | 495 mm | 495 mm | 495 mm | |
| Ground pressure: | 0.046 MPa | 0.046 MPa | 0.046 MPa | |
| ENGINE | Model & type |
Shangchai SC11CB184G2B1/Weichai WD10G178E25; 4-cycle, in-line, water-cooled, direct injection |
||
| Horsepower | Gross power: 131/175/1850 kW/HP/rpm // Net power: 120/160/1850 kW/HP/rpm | |||
| Number of cylinders | 6—126 x 130 mm (bore x stroke) | |||
| Piston displacement | 9.726 L | |||
| Min. fuel consumption | 214 g/kW·h | |||
| Maximum torque | 765 N·m@1300 rpm | |||
|
POWER
TRANSMISSION SYSTEM |
Torque converter | 3-element, 1 stage, 1 phase | ||
| Transmission | Planetary gear type, power-shift, forced lubrication | |||
| Main drive |
Spiral bevel gear, single stage speed reduction, splash lubrication |
|||
| Steering clutch |
Lubricated, multidisc, spring loaded, hand hydraulically separated, inter-linking with steering brake |
|||
| Steering brake |
Lubricated, floating band structure, foot brake with hydraulic booster |
|||
| Final drive |
2-stage speed reduction of spur gear, splash lubrication |
|||
