Quick Details
-
Engine Brand:
-
CHANGCHAI
-
Travel Speed:
-
0~8 km/h
-
Place of Origin:
-
SHN
-
Brand Name:
-
SDBM
-
Dimension(L*W*H):
-
2315*1050*1770
-
Drum diameter:
-
630 mm
-
Brand:
-
SDBM
-
Product name:
-
BM3000
-
Drive mode:
-
Variable plunger pump infinitely variable speed
-
Engine:
-
CHANGCHAI
-
Engine Model:
-
3TNV76
-
Color:
-
yellow
-
Vibrate frequency:
-
65hz
-
Drive Type:
-
hydraulic motor
-
Steel Wheel Size:
-
900*630 mm
-
Operating weight:
-
3 Ton
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
18.6 kW
-
Weight:
-
3 Ton
-
Engine Brand:
-
CHANGCHAI
-
Travel Speed:
-
0~8 km/h
-
Place of Origin:
-
SHN
-
Brand Name:
-
SDBM
-
Dimension(L*W*H):
-
2315*1050*1770
-
Drum diameter:
-
630 mm
-
Brand:
-
SDBM
-
Product name:
-
BM3000
-
Drive mode:
-
Variable plunger pump infinitely variable speed
-
Engine:
-
CHANGCHAI
-
Engine Model:
-
3TNV76
-
Color:
-
yellow
-
Vibrate frequency:
-
65hz
-
Drive Type:
-
hydraulic motor
-
Steel Wheel Size:
-
900*630 mm
-
Operating weight:
-
3 Ton
Product Description
Specification
|
Model
|
BM3000
|
|
|
WEIGHT
|
|
|
|
Operating weight
|
3000kg
|
|
|
Static line load
|
106/94 n/cm
|
|
|
DIMENSIONS
|
|
|
|
Working width
|
1355mm
|
|
|
Overall length
|
2400mm
|
|
|
Overall height with ROPS
|
2630mm
|
|
|
Turning radius(inner/outer)
|
2405/3760mm
|
|
|
Drum width
|
1200mm
|
|
|
Drum diameter
|
630mm
|
|
|
Wheel base
|
1650mm
|
|
|
DRIVE
|
|
|
|
Engine
|
Changchai ZN390B/ Yanmar 3TN88
|
|
|
Type
|
Three cylinder, water-cooled, four-stroke, diesel engine
|
|
|
Output power
|
28.5kw
|
|
|
Rated speed
|
2600rpm
|
|
|
Electric equipment
|
12V
|
|
|
Drive mode
|
Variable displacement piston pump with infinitely variable speed, two-wheel drive motor in parallel
|
|
|
Walking speed
|
0-10km/h
|
|
|
Climbing ability (vibration on/off)
|
30%/ 35%
|
|
|
BRAKES
|
|
|
|
Working brake
|
Variable displacement pump
|
|
|
STEERING
|
|
|
|
Steering method
|
Hydraulic Cylinder, Articulated Steering
|
|
|
Steering system
|
Swing articulated
|
|
|
EXCITING SYSTEM
|
|
|
|
Vibration drum
|
Front/ front + rear
|
|
|
Driving form
|
Hydraulic motor
|
|
|
Vibration frequency
|
65hz
|
|
|
Amplitude
|
0.5mm
|
|
|
Exciting force
|
35kn/ 2*35kn
|
|
|
SPRINKLER SYSTEM
|
|
|
|
Sprinkling type
|
intermittent pressure spray
|
|
|
CAPACITY
|
|
|
|
Hydraulic oil tank
|
46L
|
|
|
Fuel tank
|
42L
|
|
|
Water tank
|
140L
|
|
Product display
Application
Packing & Delivery
Our vibratory road roller compactor can be packed as following.
1. steel frame
2,. plywood case
3. as customers' request
