Quick Details
-
Model Number:
-
SUL181h
-
Max. Current:
-
16A
-
Product name:
-
Timer Switch
-
Voltage:
-
AC110-250V
-
Display:
-
Mechanical
-
cerification:
-
CE
-
Frequency:
-
50-60 Hz
-
Warranty:
-
2 Years
-
Minimum Setting Unit:
-
15 Minute
-
Installation Type:
-
DIN-rail
-
Brand:
-
SHCET OEM ODM
-
Set up Times:
-
30m/per time 48 tims
-
Certification:
-
CE
Quick Details
-
Max. Voltage:
-
240VAC, 110V OR 220V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SHCET
-
Model Number:
-
SUL181h
-
Max. Current:
-
16A
-
Product name:
-
Timer Switch
-
Voltage:
-
AC110-250V
-
Display:
-
Mechanical
-
cerification:
-
CE
-
Frequency:
-
50-60 Hz
-
Warranty:
-
2 Years
-
Minimum Setting Unit:
-
15 Minute
-
Installation Type:
-
DIN-rail
-
Brand:
-
SHCET OEM ODM
-
Set up Times:
-
30m/per time 48 tims
-
Certification:
-
CE
1.Product Application
SUL181h mechanical timer switch can be widely used in neon lights, water heaters, street lights, stair lights, breeding, garden watering, motors, advertising boxes, automatic control of office facilities and other occasions where civil or industrial electricity needs to be controlled regularly, and can be automatically controlled according to the required time.
The daily programmable time switch isprogrammed using switching segments, it's quickly read and easy to change. The time relay shortest switching time is 30 minutes and it can switching with continuous ON/AUTO/continuous OFF.
The daily programmable time switch isprogrammed using switching segments, it's quickly read and easy to change. The time relay shortest switching time is 30 minutes and it can switching with continuous ON/AUTO/continuous OFF.
2.Product Description
SUL181h main technical parameters:
* Power supply: AC110V/AC220V
* Power frequency: 50-60Hz
* Power consumption: 2W
* Driver mode: quartz motor
* Contact capacity: resistance 16A
Incandescent lamp 10A
Reactance (cosφ=0.7) 12A
Motor (cosφ=0.7) 110VAC 750W, 220VAC 1500W
* Minimum setting time: 30 minutes.
* Number of actions: standard 48 actions
* Circuit output: 1 circuit (normally open, normally closed)
* Cycle: 24 hour timer switch
* Power failure compensation: 150 hours (built-in battery)
* Operating environment temperature: -10℃～+50℃ (no freezing)
* Weight: 175g
* Power supply: AC110V/AC220V
* Power frequency: 50-60Hz
* Power consumption: 2W
* Driver mode: quartz motor
* Contact capacity: resistance 16A
Incandescent lamp 10A
Reactance (cosφ=0.7) 12A
Motor (cosφ=0.7) 110VAC 750W, 220VAC 1500W
* Minimum setting time: 30 minutes.
* Number of actions: standard 48 actions
* Circuit output: 1 circuit (normally open, normally closed)
* Cycle: 24 hour timer switch
* Power failure compensation: 150 hours (built-in battery)
* Operating environment temperature: -10℃～+50℃ (no freezing)
* Weight: 175g
Good quality SUL181h Mechanical Timer Switch with 30 Minutes 24 Hours AC 110V 240V 15A Din Rail type price from SHCET
