Quick Details
-
Components space:
-
0.2mm
-
No.of nozzles:
-
Dual mode, totally 18
-
Feeder type:
-
Electronic feeder
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ETON
-
Model Number:
-
HT-E8-1200
-
Components space:
-
0.2mm
-
No.of nozzles:
-
Dual mode, totally 18
-
Feeder type:
-
Electronic feeder
| HT-E8-1200/Technical Parameter | |
| Length*Width*Height | 2950mm*2150mm *1500mm |
| Total Weight | 1800kg |
| PCB Length Width | Max:1200*350mm Min:50*50mm |
| PCB Thickness | 0.5-5mm |
| PCB Clamping | Adjustable pressure pneumatic |
| Mounting Mode | Group picking and separate placing\separate picking and separate placing |
| Software | Windows 7 |
| Display | LED Monitor |
| Input Device | Keyboard,Mouse |
| No. of Camera | 4 sets of imported camera |
| Position Camera | Vision for the flight identification + MARK correction |
| Mounting Precision | ±0.02mm chip |
| Mounting Height | 13±2mm |
| Mounting Speed | 80000 CPH(optimum) |
| Components | LED chip,capacitors,resistors,IC,shaped components etc. |
| Components Space | 0.2mm |
| Power | 220AC 50HZ |
| Power Consumption | 8kw |
| Air Force | 0.5~0.6mpa |
| Operating Environment | 23 ℃ ±3 |
| Conveyor Transmission | Max Length:1200mm |
| Transmission Direction | > 500mm/s |
| Transmission Direction | Single(left→right or right→left) |
| Transmission Mode | Online drive |
| Air pressure | > 5.0kg/cm2 |
| Air consumption | < 200L/min |
| Electrical control | Independent research and development by ETON |
| Motion control card module 2 sets | Independent research and development by ETON |
| X,Y Axies Driving | Servo motor |
| No. of feeders | 2*20PCS |
| No. of nozzles | Dual mode,totally 18 nozzles |
| Feeder type | Electronic feeder |
F eatures:
Dual system,dual module multi-functional chip mounter.
Mounting parts: LED, capacitors, resistors, IC, Shaped components, etc.
Exclusive patented technology:
Electronic feeder feeding system, Vision for the flight identification, MARK correction, Non-stop refueling capabilities, Auto-optimization feature after coordinates generated, etc., At the same time the production of two different products.
Company's information
Shenzhen Eton Automachine Equipment co., LTD. is a professional supplier of pick and place machine, is a high-tech enterprise which specializing in R&D and manufacturing of high-end SMT pick and place machine.Our company independent research and development,design,manufacture a set of the world's fastest,most stable,most complete high-speed LED automatic energy mounter ,while also solved the offset,cast material problems of the production of 1.2m,1.5m light panels and the headlights pearl and we received a number of patents issued by the state certificate and support. We have served many electronicsfactories(LED, PCB production line etc) and enjoyed good reputation. Nowadays, we have serveral 2015 newest items launched and being hot selling, for performance and competetive price.
Company five level managerment policy
: sincere business,focus on R&D,manufacturing intentions,considerate service,customer trust.
"
No worries"after sale service concept:
the Pearl River Delta region to arrive within 4 hours, day to solve;Guangdong Province 24 hours.
Eton mission
:
professional,excellent technology,sharing the results.
Eton goal:
to create a national brand,build international Chinese enterprise.
Eton purpose
:
to create value for customers,creating benefits for society.
Services: Maintenance period: 1 year.
Visit customers regularly and gather information.
Provide latest information about technology and equipment.
Our partners
Why choose us!!
Not only we will provide the fastest,most stable and most complete LED pick and place machine for you,but also we can make the most suitable plan for you to save labor cost.
Professional is our truth.
If you're interested in our products and want to enter LED light business, please contact me at any time. Thanks!
