--High Efficiency Pv Cells--Appearance Consistency
--Anti PID
--Color sorting ensure consistent appearance on each module
--Translucency of normal luminosity is increased by 2%
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
10 years, 25 Years Output Power Guarantee
-
Brand Name:
-
Lovsun
-
Model Number:
-
LD-P60265-290
-
Place of Origin:
-
China Anhui
-
Panel Dimensions:
-
1650*992*35mm(65.0*39.1*1.38inches)
-
Product name:
-
Poly Solar Panel
-
Certificate:
-
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO, TUV
-
Application:
-
Solar Power System
-
Junction Box:
-
IP67 Rated
-
Weight:
-
18.5 Kg (41.0 Lb)
-
Frame:
-
Anodized Aluminium Alloy
-
Cell Type:
-
Poly 5BB 156x156mm Cell
-
Power:
-
285w
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Type:
-
PERC
-
Panel Efficiency:
-
17.7
-
Warranty:
-
10 years, 25 Years Output Power Guarantee
-
Brand Name:
-
Lovsun
-
Model Number:
-
LD-P60265-290
-
Place of Origin:
-
China Anhui
-
Panel Dimensions:
-
1650*992*35mm(65.0*39.1*1.38inches)
-
Product name:
-
Poly Solar Panel
-
Certificate:
-
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO, TUV
-
Application:
-
Solar Power System
-
Junction Box:
-
IP67 Rated
-
Weight:
-
18.5 Kg (41.0 Lb)
-
Frame:
-
Anodized Aluminium Alloy
-
Cell Type:
-
Poly 5BB 156x156mm Cell
-
Power:
-
285w
Product Description
ELECTRICAL DATA(STC)
|
Peak Power Watts-PMAx (Wp)
|
270
|
275
|
280
|
285
|
290
|
||||
|
Maximum Power Voltage-VMpp (V)
|
30.9
|
31.1
|
31.4
|
31.6
|
31.9
|
||||
|
Maximum Power Current-lMPP (A)
|
8.73
|
8.84
|
8.92
|
9.02
|
9.09
|
||||
|
Open Circuit Voltage-Voc (V)
|
37.9
|
38.1
|
382
|
38.3
|
38.5
|
||||
|
Short Circuit Current-lsc(A)
|
9.22
|
9.32
|
9.40
|
9.49
|
9.65
|
||||
|
Module Efficiency r> (%)
|
16.5
|
16.8
|
17.1
|
17.4
|
17.7
|
||||
|
Power Output Tolerance-PMAx (W)
|
0-+5
|
|
|
|
|
||||
|
STC Irradiance
|
1000W/m2, CellTemperature 25°C Air Mass AM1.5.
|
|
|
|
|
||||
Detailed Images
Junction Box
--Long service life,100% waterproof
--Heat dissipation
-- IP68 protection level
--Conventional standalone edition and engineering custom edition
--Quality diode ensures module running safety
--Heat dissipation
-- IP68 protection level
--Conventional standalone edition and engineering custom edition
--Quality diode ensures module running safety
Aluminum frame
--Conventional frame
--Boost bearing capability and prolong service life
--Serrated-clip design tensile strength
--Seal-lip design glue injection
--Silver or black frames are optional
--Boost bearing capability and prolong service life
--Serrated-clip design tensile strength
--Seal-lip design glue injection
--Silver or black frames are optional
Produce Line&Packing
Our produce line
Our detection system.
Packing
Product Certification
Delivery & Payment Terms
|
Payment Terms
|
T/T
|
EXW
|
30% in advance for deposit payment, the balance payments will be paid before shipment.
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR/C&F
|
30% in advance for deposit payment, the balance will be paid against copy of B/L
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
L/C
|
For the amount of one shipment above 50,000 usd, L/C at sight is acceptable.
|
|
|
|||
|
|
West Union
|
|
|
|
|||
|
|
Paypal
|
|
|
|
|||
|
Delivery Time
|
7~25 days after receiving the payment or the deposit payment
|
|
|
|
|||
We recommend you use alibaba Insurance Order Online, you will enjoy
100% Products quality protection
100% On time shipment
100% Payment safety protection
The third party inspection is optional
