Quick Details
-
Model Number:
-
4WE3 4WE4 4WE5
-
Brand Name:
-
DI-FONG
-
Product name:
-
High
-
Body material:
-
Carbon Steel
-
Connection:
-
Female Thread
-
Medium:
-
Water Oil Gas
-
Name:
-
Hydraulic Spare Parts
-
Type:
-
Closed, ball float valve
-
Certificate:
-
ISO9001
-
Standard:
-
ASTM
Quick Details
-
Port Size:
-
Standard
-
Warranty:
-
1 year
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
4WE3 4WE4 4WE5
-
Brand Name:
-
DI-FONG
-
Product name:
-
High
-
Body material:
-
Carbon Steel
-
Connection:
-
Female Thread
-
Medium:
-
Water Oil Gas
-
Name:
-
Hydraulic Spare Parts
-
Type:
-
Closed, ball float valve
-
Certificate:
-
ISO9001
-
Standard:
-
ASTM
[Product Features]
1. Direct-acting solenoid operational direction valve as standard type.
2. Installation area by DIN24 340 type A
3. DC or AC wet-type solenoid that can be arbitrary rotation and with detachable coil.
4. Coil can be replaced without oil.
5. Equipped with manual emergency operation push rod.
2. Installation area by DIN24 340 type A
3. DC or AC wet-type solenoid that can be arbitrary rotation and with detachable coil.
4. Coil can be replaced without oil.
5. Equipped with manual emergency operation push rod.
[Technical Data]
General data
|
Mounting position
|
|
anywhere
|
|
|
Operating temperature ℃
|
|
-30~+50(nitrile rubber seal)
|
|
|
|
|
-20~+50(rubber seal)
|
|
|
weight
|
Single solenoid valve kg
|
1.45
|
|
|
|
Double solenoid valve kg
|
1.95
|
|
Hydraulic Data
|
Maximum operating voltage fluid port P,A,B Mpa
|
|
|
31.5
|
||
|
Hydraulic fluid port Mpa
|
|
|
21(DC):16(AC)
When working pressure exceeds the allowable pressure, valves with the sign bit A,B must use T as oil drain port |
||
|
Maximum flow rate 1/min
|
|
|
80(DC); 60(AC)
|
||
|
Flux areas (when in the median)
|
Type Q
|
mm2
|
About 6% of the nominal cross-sectional area
|
||
|
|
Type W
|
mm2
|
About 6% of the nominal cross-sectional area
|
||
|
Hydraulic oil
1,suitable for nitrile rubber and fluoro rubber seal 2,Fluoro seal only |
|
|
Mineral oil(HL,HLP) by DIN51 524
Rapid biological solution oil by VDMA24 568 HETG 1); HEPG 2);HEES 3) |
||
|
The oil temperature range ℃
|
|
|
-30~+80(nitrile rubber seal)
|
||
|
|
|
|
-20~+80(rubber seal)
|
||
|
Viscosity range mm2/s
|
|
|
2.8-500
|
||
|
Oil cleanliness
|
|
|
The highest oil pollution level by NASI1639 Class 9
recommend minimum filter filtration precision β10 exceed 75 |
||
