Quick Details
-
Size:
-
L12500*W4000*H3000mm
-
Material:
-
Hot dip galvanized frame
-
Warranty:
-
3 Year
-
Product name:
-
industrial brusher car washing machine system
-
Model:
-
Q9 tunnel Washing car system Russia
-
Water consumption:
-
80-150L/car
-
Electricity consumption:
-
0.6 degree/car
-
Power:
-
25KW
-
Power resource:
-
380V 50HZ 20KVA
-
Air Supply:
-
Pressure 0.75-0.9Mpa
-
Installation Ground Flatness:
-
deviation≤20mm
-
Wash Time:
-
2.5-3min/car
-
Shinewash car wash machine service life:
-
>15 years
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
SHINEWASH
-
Model Number:
-
Q9
-
Size:
-
L12500*W4000*H3000mm
-
Material:
-
Hot dip galvanized frame
-
Warranty:
-
3 Year
-
Product name:
-
industrial brusher car washing machine system
-
Model:
-
Q9 tunnel Washing car system Russia
-
Water consumption:
-
80-150L/car
-
Electricity consumption:
-
0.6 degree/car
-
Power:
-
25KW
-
Power resource:
-
380V 50HZ 20KVA
-
Air Supply:
-
Pressure 0.75-0.9Mpa
-
Installation Ground Flatness:
-
deviation≤20mm
-
Wash Time:
-
2.5-3min/car
-
Shinewash car wash machine service life:
-
>15 years
Do you want to join Shinewash agency?Request to contact us!
Just click the "Chat Now" button to get in touch and you'll hear
backfrom us. We look forward to hearing from you
backfrom us. We look forward to hearing from you
Industrial brusher full automatic car washing machine systems auto car washing equipment with prices machine for suv
product details
Product Features:
* Fully automated
* Efficient washing,safe and convenient
* Intelligent and efficient control
* Control it yourself remotely
* Up to complete washing 60 vehicles per hour
* Fully automated
* Efficient washing,safe and convenient
* Intelligent and efficient control
* Control it yourself remotely
* Up to complete washing 60 vehicles per hour
*With three-in-one maintenance function of foam, water wax and coating
Washing mode：
Firstly:high pressure water pre-washing
Secondly:Non-stick sand brush cleaning
Applicable Vehicles:
Small vehicles such as sedans, SUV etc.
Firstly:high pressure water pre-washing
Secondly:Non-stick sand brush cleaning
Applicable Vehicles:
Small vehicles such as sedans, SUV etc.
Industrial brusher full automatic car washing machine systems auto car washing equipment with prices machine for suv
Main Accessories Show:
PLC Control Systerm
Fully automatic Mitsubishi PLC computer control
system,faster operation speed,lower failure rate, and can be upgraded remotely.
Frequency Converter
Siemens brand
Branded Moter Reducer
Famous
brand,Stable performance and less failure.
Photoelectric Sensor
Banner Brand,from America
Type:S186E/S18SN6R
New Intelligent Air drying Control System
22KW high power Air drying system show
Quality EVA Brush
5 Foam brush(1 vertical lift top brush + 2 small vertical brushes + 2 large vertical brushes), not hurt the car
Product Photos
Industrial brusher full automatic car washing machine systems auto car washing equipment with prices machine for suv
Show:
Q7 tunnel car wash machine project in Thailand
Q9
tunnel car wash machine project
in Malaysia
S1 gantry rollover car wash machine project in Russia
Q7 tunnel car wash machine project
project in Africa
Industrial brusher full automatic car washing machine systems auto car washing equipment with prices machine for suv
which are best selling!
|
auto automatic tunnel car washing wash system technical data,any other requirements can be customized.
|
|
|
|
|
||||
|
Machine Size (m)
|
L12.5*W4*H3
|
|
|
|
||||
|
Installation Size (m)
|
L24*W4.5*H3.2
|
|
|
|
||||
|
Washing Size (m)
|
L≤unlimited*W≤2.3H≤2.1
|
|
|
|
||||
|
Shipping Volume
|
16m³
|
|
|
|
||||
|
6Shipping Weight
|
6 ton
|
|
|
|
||||
|
Moving Speed
|
frequency control
|
|
|
|
||||
|
Power
|
20KW
|
|
|
|
||||
|
Voltage
|
380V 50Hz
|
|
|
|
||||
|
Compressed Air Supply
|
0.75~0.9Mpa air flow rate≥0.6m^3/min
|
|
|
|
||||
|
Water Supply
|
DN25mm water flow rate≥200L/min
|
|
|
|
||||
|
Water Consumption
|
80-150L/car
|
|
|
|
||||
|
Electricity Consumption
|
0.6KWH/Car
|
|
|
|
||||
|
Shampoo Consumption
|
7ML/Car
|
|
|
|
||||
|
Water Wax Consumption
|
12ML/Car
|
|
|
|
||||
|
Wash Cost
|
Approx. 1.5 yuan/car
|
|
|
|
||||
|
Top Brush
|
1
|
|
|
|
||||
|
Big Vertical Brush
|
4
|
|
|
|
||||
|
Skirt Brush
|
4
|
|
|
|
||||
