Quick Details
-
Warranty:
-
10, 25 Years Output Power Guarantee
-
Brand Name:
-
Donghui
-
Model Number:
-
YWDH-20W
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
480*350*25mm
-
Solar cell:
-
Mono 156*80Cell
-
Certificate:
-
ISO CE
-
Application:
-
Solar Home System
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
7.6kg
-
OEM Order:
-
Customized Solar Panel Aavilable
-
Front Glass:
-
3.2mm Tempered Glass
-
Rated voltage:
-
18v
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC
-
Panel Efficiency:
-
20%
-
Warranty:
-
10, 25 Years Output Power Guarantee
-
Brand Name:
-
Donghui
-
Model Number:
-
YWDH-20W
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
480*350*25mm
-
Solar cell:
-
Mono 156*80Cell
-
Certificate:
-
ISO CE
-
Application:
-
Solar Home System
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
7.6kg
-
OEM Order:
-
Customized Solar Panel Aavilable
-
Front Glass:
-
3.2mm Tempered Glass
-
Rated voltage:
-
18v
Product Description
| name | size(mm) | Weight(kg) | Operating Voltage(v) | Working current(A) | Open circuit voltage(V) | Short circuit current(A) |
| 10W mono | 350*250*17 | 1 | 17.85 | 0.56 | 21.73 | 0.61 |
| 10W poly | 350*250*17 | 1 |
17.83 |
0.56 |
21.75 | 0.61 |
| 20W mono | 460*350*17 | 1.9 | 17.88 | 1.12 | 21.24 | 1.23 |
| 20W poly | 480*350*20 | 1.9 | 17.87 | 1.12 | 21.23 | 1.23 |
| 30W mono | 640*350*25 | 2.8 | 17.89 | 1.68 | 21.48 | 1.85 |
| 30W poly | 630*350*20 | 2.8 | 17.89 | 1.68 | 21.48 | 1.86 |
| 50W mono | 670*540*25 | 4 | 17.5 | 2.86 | 21.5 | 3.18 |
| 50W poly | 670*540*25 | 4 | 17.54 | 2.85 | 21.51 | 3.14 |
| 60W mono | 620*670*25 | 4.8 | 17.8 | 3.4 | 21.7 | 3.76 |
| 60W poly | 620*670*25 | 4.8 | 17.84 | 3.36 | 21.75 | 3.69 |
| 80W mono | 800*670*30 | 6 | 17.8 | 4.5 | 22.13 | 4.98 |
| 80W poly | 800*670*30 | 6 | 17.6 | 4.55 | 21.9 | 4.85 |
| 100W mono | 1000*670*30 | 7.6 | 18.02 | 5.55 | 22.12 | 5.98 |
| 100W poly | 1000*670*30 | 7.6 | 17.53 | 5.71 | 21.25 | 6.03 |
