Quick Details
-
Brand Name:
-
None
-
Supplier Type:
-
OEM/ODM
-
Frequency Range:
-
136~174MHz, 220~240MHz, 410~470MHz
-
Interface Type:
-
RS232&RS485 or TTL&RS485
-
Software Program:
-
Yes
-
Air data rate:
-
1200bps-115200bps settable by user
-
Baud rate:
-
1200bps-115200bps settable by user
-
Transmit Power:
-
50W/35W/25W
-
Transmission Distance:
-
30-50km(Line of sight)
Quick Details
-
Application:
-
scada system
-
Model Number:
-
XZ-DT25-H
-
Place of Origin:
-
Shenzhen,China
-
Brand Name:
-
None
-
Supplier Type:
-
OEM/ODM
-
Frequency Range:
-
136~174MHz, 220~240MHz, 410~470MHz
-
Interface Type:
-
RS232&RS485 or TTL&RS485
-
Software Program:
-
Yes
-
Air data rate:
-
1200bps-115200bps settable by user
-
Baud rate:
-
1200bps-115200bps settable by user
-
Transmit Power:
-
50W/35W/25W
-
Transmission Distance:
-
30-50km(Line of sight)
Product Description
Product Features
♦
Support frequency VHF(136MHZ-174MHZ,220-240MHZ)UHF(410MHZ-470MHZ) user program;
♦ RS232&RS485 2 interface default,TTL can be set in factory;
♦ High receiving sensitivity up to -125dBm;
♦ Over-the-air data rate from 1200bps to 115200bps and baud rate 1200-115200bps user programming;
♦ Short transmitting-receiving transfer time; communication delay less than 3Ms.
♦ RS232&RS485 2 interface default,TTL can be set in factory;
♦ High receiving sensitivity up to -125dBm;
♦ Over-the-air data rate from 1200bps to 115200bps and baud rate 1200-115200bps user programming;
♦ Short transmitting-receiving transfer time; communication delay less than 3Ms.
Technical Parameters
|
Frequency Range
|
136～174MHz, 220～240MHz, 410～470MHz
|
|
Frequency stability
|
≤±2.5PPm
|
|
Transmit Power
|
50W,35W,25W
|
|
Modulation
|
GFSK/4GFSK
|
|
Air Data Rate
|
1200～115200bps settable by user
|
|
Baud Rate
|
1200～115200bps settable by user
|
|
Interface
|
RS232 and RS485 default, TTL customized
|
|
Power Supply
|
12V@10A
|
|
Interface Data Format
|
8E1/8N1/801
|
|
Receiving Sensitivity
|
-125dBm@1200bps/-120dBm@9600bps
|
|
Channel Bandwidth
|
10KHZ@1200bps/25KHZ@9600bps
|
|
Emission Current
|
≤150mA
|
|
Receiving Current
|
≤50mA
|
|
Working Temperature&humidity
|
-40℃～80℃ (industrial grade),10% to 90% relative humidity, no condensation
|
|
Dimension(L/W/H)
|
145X 86X 40mm
|
|
Weight(g)
|
≤500g
|
Pin Definitions
Software Program
Applications
* Marine Communication
* water wells, water and waste water treatment monitoring system
* Oil and gas production, pipeline monitoring, gas distribution, heat network monitoring
* Power scheduling, distribution automation, load control
* GPS positioning system, mobile data transmission
* Vessel (UMV) monitoring and control, robot control data link
* Army, police communications
* Earthquake, meteorology, environmental protection and urban lighting control
* Railway, transportation, metallurgy, chemical industry and industrial automation process control
* Industrial remote control, telemetry, automated data acquisition system
* water wells, water and waste water treatment monitoring system
* Oil and gas production, pipeline monitoring, gas distribution, heat network monitoring
* Power scheduling, distribution automation, load control
* GPS positioning system, mobile data transmission
* Vessel (UMV) monitoring and control, robot control data link
* Army, police communications
* Earthquake, meteorology, environmental protection and urban lighting control
* Railway, transportation, metallurgy, chemical industry and industrial automation process control
* Industrial remote control, telemetry, automated data acquisition system
