Quick Details
-
Model Number:
-
YM-HY-1720000
-
Brand Name:
-
YM MOTOR, YMMOTOR
-
Warranty:
-
3months-1year
-
Max Speed::
-
180km/h
-
Peak Torque:
-
400N.m
-
Commutation:
-
Brushless
-
Speed(RPM):
-
1300
-
Efficiency:
-
90%
-
Drop-out:
-
220mm
-
Continuous Current(A):
-
10A-83A
-
Motor Type:
-
Brushless Direct Current Motor(BLDC Motor)
Quick Details
-
Voltage:
-
72V
-
Style:
-
Two rounds
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
YM-HY-1720000
-
Brand Name:
-
YM MOTOR, YMMOTOR
-
Warranty:
-
3months-1year
-
Max Speed::
-
180km/h
-
Peak Torque:
-
400N.m
-
Commutation:
-
Brushless
-
Speed(RPM):
-
1300
-
Efficiency:
-
90%
-
Drop-out:
-
220mm
-
Continuous Current(A):
-
10A-83A
-
Motor Type:
-
Brushless Direct Current Motor(BLDC Motor)
Product Description
Specification
|
Axle Configuration
|
Double
|
|
Voltage
|
72V
|
|
Wheel Rim
|
17X6.0
|
|
wiring harness
|
30
2
|
|
Design
|
Brushless
|
|
Style
|
Two rounds
|
|
Magnet Height
|
70mm
|
|
Speed(RPM)
|
1300
|
|
Rated Speed
|
180km/h
|
|
Model Number
|
YM-HY-1720000
|
|
Brand Name
|
YM MOTOR
|
|
Wheel Rim
|
17inch
|
|
Brake System
|
Disc Brake
|
|
Peak Torque:
|
400N.m
|
|
Hall Sensors
|
2
|
|
Hall Sensor Phasing
|
120°
|
|
Number of motor phases
|
3
|
|
Number of Pole Pairs
|
16
|
|
Cross Section of Phase Wire
|
6 Square
|
|
Efficiency
|
90%
|
|
Waterproof Grade
|
IP67
|
|
Color
|
Black/white etc.
|
|
Cross Section of Phase Wire
|
252mm
|
|
Drop-out
|
220mm
|
|
Continuous Current(A)
|
10A-83A
|
|
Motor Type
|
Brushless Direct Current Motor(BLDC Motor)
|
|
Package
|
Carton
|
HOT PRODUCTS
Notice:
JungTeng YM Motor could work 120 ℃ in half an hour without damage.
Suggestion (Setting of Controller)
When it's 130 ℃ inside of motor (in 30s), the current should be limited 50%.
When it's 150 ℃, the controller shut down. When it drop down to 110℃, the controller work again.
More JunTeng YM Motor Informaiton:
Optional Appearance
Motor Details, drawing, performance curve .
For more information, please feel free to contact with us.
JungTeng YM Motor could work 120 ℃ in half an hour without damage.
Suggestion (Setting of Controller)
When it's 130 ℃ inside of motor (in 30s), the current should be limited 50%.
When it's 150 ℃, the controller shut down. When it drop down to 110℃, the controller work again.
More JunTeng YM Motor Informaiton:
Optional Appearance
Motor Details, drawing, performance curve .
For more information, please feel free to contact with us.
