Quick Details
-
Certification:
-
CE
Quick Details
-
Displacement:
-
200cc
-
Brand Name:
-
BossATV
-
Place of Origin:
-
Zhejiang, China
-
Certification:
-
CE
|
Engine |
|
|
Engine Type |
Single cylinder, air-cooled, 4-stroke, fully automatic with reverse |
|
Engine Displacement |
150cc or 200cc(oil-cooled) |
|
Bore & Stroke |
57.40x57.80mm[200cc: 62.5x65.2mm] |
|
Compression Ratio |
10:1 |
|
Carburetor |
Carburetor |
|
Max. Power Output |
6.4kW/(7000r/min) [200cc: 7.5kW/(7500r/min)] |
|
Max. Torque |
9.0N.m/(6000r/min)[200cc: 10.5N.m/(5500r/min)] |
|
Ignition |
CDI |
|
Starter |
Electric start + kick start |
|
Drive Train |
|
|
Clutch |
Fully automatic |
|
Gearbox |
1 forward, neutral and 1 reverse gear |
|
Final Drive |
Chain |
|
Dimensions and Weight |
|
|
Length x Width x Height |
1,830 x 1,100 x 1,370mm |
|
Wheelbase |
1,210mm |
|
Front Tread |
1,000mm |
|
Rear Tread |
760mm |
|
Seat Height |
890mm |
|
Foot Step to Seat |
480mm |
|
Fuel Capacity |
7.8L , metal tank |
|
Dry Weight |
154kg |
|
Max. Load |
167kg |
|
Wheels, Suspension and Brakes |
|
|
Wheels Front |
10 inch iron rim |
|
Wheels Rear |
10 inch iron rim |
|
Tyres Front |
23x7-10 |
|
Tyres Rear |
22x10-10 |
|
Suspension Front |
Independent double-wishbone |
|
Suspension Rear |
Swing arm with single shock |
|
Brakes Front |
Dual hydraulic disc brakes(Hand operated + foot operated) |
|
Brakes Rear |
Hydraulic disc brake(Hand operated + foot operated) |
|
Packing |
|
|
Carton Size |
1,500x830x810mm |
|
G.W./N.W. |
174/154kg |
|
Container Load |
20pcs/42pcs/63pcs |
