- Product Details
- {{item.text}}
Quick Details
-
Driven Type:
-
LABELING MACHINE
-
Voltage:
-
220V
-
Place of Origin:
-
China, China Guangdong China
-
Brand Name:
-
UBL
-
Dimension(L*W*H):
-
1930MM*1120MM*1340MM
-
Weight:
-
null null
-
Machinery Capacity:
-
30~220 pcs/min
-
Air pressure(Mba):
-
0.6
-
Label size:
-
L280*W280
-
Power(KW):
-
1
-
After-sales Service Provided:
-
Online support
-
Bag maximum size (mm):
-
Length20~300mm;Width15~165mm
-
Product size(Vertical):
-
Diameter30~100mm;height:15~300mm
-
Label requirement:
-
Roll label;Inner dia 76mm;Outside roll≤300mm
-
Certification:
-
ISO 9001/CE
Quick Details
-
Application:
-
Food, Beverage, Commodity, Chemical, Machinery & Hardware, APPAREL, Textiles
-
Packaging Type:
-
Bottles
-
Packaging Material:
-
Plastic, Paper
-
Driven Type:
-
LABELING MACHINE
-
Voltage:
-
220V
-
Place of Origin:
-
China, China Guangdong China
-
Brand Name:
-
UBL
-
Dimension(L*W*H):
-
1930MM*1120MM*1340MM
-
Weight:
-
null null
-
Machinery Capacity:
-
30~220 pcs/min
-
Air pressure(Mba):
-
0.6
-
Label size:
-
L280*W280
-
Power(KW):
-
1
-
After-sales Service Provided:
-
Online support
-
Bag maximum size (mm):
-
Length20~300mm;Width15~165mm
-
Product size(Vertical):
-
Diameter30~100mm;height:15~300mm
-
Label requirement:
-
Roll label;Inner dia 76mm;Outside roll≤300mm
-
Certification:
-
ISO 9001/CE
Products Description
Automatic labeling machine
Function introduction
UBL automatic round bottle labeling machine applicable to circumferential labeling of various cylindrical products. Such as cosmetic bottles, shampoo bottles, shower gel bottles,medicine bottles, jam bottles, essential oil bottles, sauce bottles, wine bottles,mineral water bottles, beverage bottles, glue bottles,Metal can, milk powder canetc.
The round bottle labeling machine can be labeled single and double,can add bottle unscrambler.
Product Paramenters
|
Automatic round bottle labeling machine
|
|
|
|
Type
|
UBL-T-400
|
|
|
Label Quantity
|
One or two labels at a time
|
|
|
Accuracy
|
±0.5mm
|
|
|
Speed
|
25~55pcs/min
|
|
|
Label size
|
Length20~300mm;Width15~165mm
|
|
|
Product size(Vertical)
|
Diameter30~100mm;height:15~300mm
|
|
|
Label requirement
|
Roll label;Inner dia 76mm;Outside roll300mm
|
|
|
Machine size and weight
|
L1950mm*W1200mm*H1530mm; 200Kg
|
|
|
Packing size weight
|
L1910*W1120*L1670mm；about 350kg
|
|
|
Power
|
AC 220V ; 50/60HZ
|
|
|
Additional features
|
1.Can add the ribbon coding machine
2.Can add
transparent sensor
3.Can add
inkjet printer or laser printer
4.Can add Circular positioning function |
|
|
Configuration
|
PLC control;Have sensor;Have touch screen;Have conveyor belt;Have cylinder;Need air compressor
|
|
|
When the bottle labeling position is recessed, and need Positioning labeling .it is suitable to use this machine.
|
|
|
