Quick Details
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Solar
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Fixed frequency
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Greensun/OEM
-
Model Number:
-
GS12000BTU /18000BTU /24000BTU
-
COP:
-
11.95
-
Power (W):
-
1000
-
Voltage (V):
-
220
-
Featured Function:
-
WIFI Monitoring via Phone
-
Recommended Room Size（square feet）:
-
20-30 suqare meters(m2)
-
Product name:
-
Air-Conditioner
-
Refrigerant type:
-
R410a
-
Function:
-
Cooling Heating
-
Power supply:
-
110-120V/ 208-230V/ 220-240v
-
Name:
-
Air Conditioners Split System
-
Compressor:
-
Rare earth compressor
-
Color:
-
White
-
Cooling capacity:
-
12000BUT 18000BUT 24000BTU
-
NOISE LEVEL:
-
42dB(A)
Quick Details
-
Capacity (btu):
-
12000BTU /18000BTU /24000BTU
-
EER:
-
11.75
-
Type:
-
Split Wall Mounted Air Conditioners
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Solar
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Fixed frequency
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Greensun/OEM
-
Model Number:
-
GS12000BTU /18000BTU /24000BTU
-
COP:
-
11.95
-
Power (W):
-
1000
-
Voltage (V):
-
220
-
Featured Function:
-
WIFI Monitoring via Phone
-
Recommended Room Size（square feet）:
-
20-30 suqare meters(m2)
-
Product name:
-
Air-Conditioner
-
Refrigerant type:
-
R410a
-
Function:
-
Cooling Heating
-
Power supply:
-
110-120V/ 208-230V/ 220-240v
-
Name:
-
Air Conditioners Split System
-
Compressor:
-
Rare earth compressor
-
Color:
-
White
-
Cooling capacity:
-
12000BUT 18000BUT 24000BTU
-
NOISE LEVEL:
-
42dB(A)
Product Description
CE Certified, Three Phase Hybrid Inverter 30KW 50KW 100KW 120KW 150KW, High Battery Voltage.
Lithium/Lead Acid battery/Lead Carbon Battery Compatible
It is a good choice for ESS, BESS, Home Energy Storage System, Solar Energy Storage System and so on.
Specification
|
|
GRS30-EU
|
GRS50-EU
|
GRS100-EU
|
GRS120-EU
|
GRS150-EU
|
||||
|
Max. PV open-circuit voltage
|
1000V DC
|
|
|
|
|
||||
|
Max. PV power
|
45kWp
|
75kWp
|
150kWp
|
180kWp
|
225kWp
|
||||
|
PV MPPT voltage range
|
480V-800V DC
|
|
|
|
|
||||
|
Battery voltage range
at Max. charge power |
450V-600V
|
500V-600V
|
500V-600V
|
517V-600V
|
500V-600V
|
||||
|
Battery voltage range
|
352-600V
|
|
352-600V
|
|
|
||||
|
Max. charge power
|
45kW
|
75kW
|
150kW
|
180kW
|
225kW
|
||||
|
Max. discharge power
|
33kW
|
55kW
|
110kW
|
132kW
|
165kW
|
||||
|
Max. charge current
|
100A
|
150A
|
300A
|
350A
|
450A
|
||||
|
Max. discharge current
|
93A
|
156A
|
313A
|
374A
|
467A
|
||||
|
AC Rated voltage
|
380/400V
|
|
|
|
|
||||
|
AC Rated current
|
91/87/83/79/72A
|
152/144/139/131/120A
|
304/289/278/262/241A
|
365/346/333/315/289A
|
456/433/416/394/361A
|
||||
|
Rated frequency
|
50/60Hz (45~55/55~65Hz)
|
|
|
|
|
||||
|
PF
|
0.8lagging~0.8leading
|
|
|
|
|
||||
|
AC connection
|
3/N/PE
|
|
|
|
|
||||
|
Operating temperature
|
-25 °C~+55 °C
|
|
|
|
|
||||
|
Cooling
|
Forced-air
|
|
|
|
|
||||
|
Relative humidity
|
0-95% non-condensing
|
|
|
|
|
||||
|
Maximum altitude
|
6000m (derate over 3000m)
|
|
|
|
|
||||
|
Dimension(W/H/D)
|
700/1660/600mm
|
950/1860/750mm
|
1200/1900/800mm
|
|
|
||||
|
Weight
|
355kg
|
610kg
|
948kg
|
1025kg
|
1230kg
|
||||
|
Build-in transformer
|
Yes
|
|
|
|
|
||||
|
Transfer between on/off grid
|
Automatic≤10ms
|
|
|
|
|
||||
|
Standby consumption
|
<30W
|
|
|
|
|
||||
