Quick Details
-
Power:
-
50/60Hz
-
Dimension(L*W*H):
-
2800*1080*1800mm
-
Weight:
-
1000KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support, Online support
-
Packaging form:
-
Horizontal Four-side sealing
-
Packing material:
-
CPP,PE,BOPP CPP film,PE film,BOPP film
-
Packing specification:
-
L*W :50x50mm
-
Packing speed:
-
360-600 bags/minute
-
Outline dimensions:
-
L2800xW1100xH1800mm
-
Air consumption:
-
300-500L/min
-
Air supply:
-
0.6-1.0MPa
-
Machine noise:
-
≤64.9dB(A)
-
Power supply type:
-
220V 50/60Hz
-
Certification:
-
CE
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
NEWPACK
-
Voltage:
-
220v
-
Power:
-
50/60Hz
-
Dimension(L*W*H):
-
2800*1080*1800mm
-
Weight:
-
1000KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support, Online support
-
Packaging form:
-
Horizontal Four-side sealing
-
Packing material:
-
CPP,PE,BOPP CPP film,PE film,BOPP film
-
Packing specification:
-
L*W :50x50mm
-
Packing speed:
-
360-600 bags/minute
-
Outline dimensions:
-
L2800xW1100xH1800mm
-
Air consumption:
-
300-500L/min
-
Air supply:
-
0.6-1.0MPa
-
Machine noise:
-
≤64.9dB(A)
-
Power supply type:
-
220V 50/60Hz
-
Certification:
-
CE
Product Description
Main Technical Parameter
|
Product Name
|
wet wipes making machine
|
Style
|
brand-new
|
|
Brand
|
NEWPACK
|
Colour
|
stainless steel
|
|
Packing speed
|
300-600bags/min..
|
Place of Product
|
Wenzhou Province,China
|
|
Packing specification
|
Length: 50mm
width:50mm
|
Modes of packing
|
Packed in one wooden case
|
|
Folding way
|
Max 1 folding vertical or 1 folding horizontal
|
Liquid added range
|
0-10ml
|
|
Package size
|
3160*1080*1900mm
|
Machine dimension
|
L2800×W1080×H1800mm
|
|
Air supply
|
0.6-1.0 Mpas
|
Machine noise
|
≤64.9dB(A)
|
|
Control panel
|
Colour touch-screen (Language On request)
|
Wrapping materials
|
Heat sealable PET, OPP,BOPP /AL/ PE, CPP laminate film.
|
|
Packaging form
|
Horizontal Four-side sealing/ three side sealing
|
Wet Tissue Material
|
30-80g/m2 air laid paper, non-woven, spun lace non-woven fabric etc
|
|
Max.ext. dia & Int.diameter
|
Max exterior diameter of film 350mm , Internal diameter 75mm
|
Max.ext. dia & Int.diameter
|
Max exterior diameter 1000mm, Internal diameter 75mm
|
Features:
1. Color touch screen, PLC control system, servo motor, automation equipment, easy operate.
2. Four-side sealing bag making, six-row bag making, sealed twice, no leakage.
3. All stainless steel non-woven fabric unwinding, folding and slicing structure.
4. The liquid metering pump of the Japanese Yiweiqi can be quantitatively operated.
5. The photoelectric eye tracks and locates the roll film color code.
6. Stable mechanical structure and equipment.
1. Color touch screen, PLC control system, servo motor, automation equipment, easy operate.
2. Four-side sealing bag making, six-row bag making, sealed twice, no leakage.
3. All stainless steel non-woven fabric unwinding, folding and slicing structure.
4. The liquid metering pump of the Japanese Yiweiqi can be quantitatively operated.
5. The photoelectric eye tracks and locates the roll film color code.
6. Stable mechanical structure and equipment.
Machine display
Packing&Shipping
Machine weight:
1100Kg
Machine dimensions:
L2800×W1080×H1800mm
Package size:
wood cases 3160*1080*1900mm one case only
Company Introduction
Shang hai Ingram Micro Packing Technology Co.,Ltd
is a wholesale company that manufactures good & high quality packing machine, starting from 2006.
Adress: No.7425 Caolang Road Jinshan District, Shanghai China
Adress: No.7425 Caolang Road Jinshan District, Shanghai China
FAQ
How can I know your machine is designed for my product?
A: If you don't mind, you can send u sample and we test it on the machine. During that time, we will take video and clearer picture for you. If chance, we can take video online and show u.
Q: How can I trust you for the first time business?
A: Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba Trade Assurance service. it will protect your money during the whole stage of the transaction.
Q: How about the after service and guarantee period?
A: We make the guarantee time 12 months from the machine's arrival in buyer's facility and we have a professional team with an experienced technician to serve abroad and do the best after service to assure the machine whole life usage.
