Quick Details
-
Brand Name:
-
Sunniest
-
Model Number:
-
BSC2024
-
Max PV Voltage:
-
100V
-
Warranty:
-
25 year
-
Rated Current:
-
20A
-
Rated Voltage:
-
DC 12V/24V Auto
-
Self-consumption:
-
≤20mA
-
Loop Voltage Drop:
-
≤0.3V
-
USB Output:
-
5V/2A*2
-
Temperature Compensation:
-
-4mV/℃/2V(25℃)
-
Operating Temperature:
-
-40℃~60℃
-
Protecting Category:
-
IP32
-
Weight:
-
0.2Kg
-
Dimensions:
-
147*82*36mm
Quick Details
-
Type:
-
PWM
-
Application:
-
Charger Controller, Voltage Controller, Solar System Controller
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sunniest
-
Model Number:
-
BSC2024
-
Max PV Voltage:
-
100V
-
Warranty:
-
25 year
-
Rated Current:
-
20A
-
Rated Voltage:
-
DC 12V/24V Auto
-
Self-consumption:
-
≤20mA
-
Loop Voltage Drop:
-
≤0.3V
-
USB Output:
-
5V/2A*2
-
Temperature Compensation:
-
-4mV/℃/2V(25℃)
-
Operating Temperature:
-
-40℃~60℃
-
Protecting Category:
-
IP32
-
Weight:
-
0.2Kg
-
Dimensions:
-
147*82*36mm
Detail Images
Products Description
Product Paramenters
|
Rated Current
|
10A/20A
|
30A/40A
|
50A/60A/80A
|
100A
|
|||
|
Rated Voltage
|
DC 12V/24V Auto (or 12V/24V/36V/48V Auto)
|
|
|
|
|||
|
Max PV Open Circuit Voltage
|
100V
|
|
|
|
|||
|
Self-Consumption
|
≤20mA
|
|
|
|
|||
|
Loop Voltage Drop
|
≤0.3V
|
|
|
|
|||
|
USB Output
|
5V/2A x2
|
|
|
|
|||
|
Temperature Compensation
|
-4mV/℃/2V (25℃)
|
|
|
|
|||
|
Operating Temperature
|
-40℃ ~ 60 ℃
|
|
|
|
|||
|
Protection Category
|
IP32
|
|
|
|
|||
|
Humidity
|
≤95%, non-condensing
|
|
|
|
|||
|
Terminals
|
10AWG/6mm
2
|
6AWG/16mm
2
|
4AWG/25mm
2
|
|
|||
|
Mounting Hole Size
|
137x52mm-Φ6mm
|
177x60mm-Φ5mm
|
190x104mm-Φ5mm
|
220x120mm-Φ5mm
|
|||
|
Dimension
|
147x82x36mm
|
187x96x47mm
|
200x132x61mm
|
230x153x62mm
|
|||
|
Weight
|
0.2kg
|
0.4kg
|
0.72kg/0.8kg
|
0.95kg
|
|||
