- Product Details
- {{item.text}}
Quick Details
-
Ink Type:
-
Eco Solvent Ink
-
Place of Origin:
-
Japan
-
Brand Name:
-
Roland
-
Voltage:
-
AC 100-120V/AC 220-240V
-
Dimensions(L*W*H):
-
2945*730*1310mm
-
Weight:
-
204KG
-
Model:
-
VG2-640
-
Printing Cutting Size:
-
1600mm
-
Cutting Speed:
-
300mm/s
-
Blade Force:
-
30-500gf
-
Blade:
-
Roland CAMM-1 series blade
-
Ink Colors:
-
4/7/8 Color
-
Printing material:
-
Vinyl Sticker Banner Wrap Wallpaper
-
Resolution:
-
1200dpi Max
-
Blade Height:
-
Up to 1.5mm
-
Certification:
-
CE
Quick Details
-
Print Dimension:
-
1600mm
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Ink Type:
-
Eco Solvent Ink
-
Place of Origin:
-
Japan
-
Brand Name:
-
Roland
-
Voltage:
-
AC 100-120V/AC 220-240V
-
Dimensions(L*W*H):
-
2945*730*1310mm
-
Weight:
-
204KG
-
Model:
-
VG2-640
-
Printing Cutting Size:
-
1600mm
-
Cutting Speed:
-
300mm/s
-
Blade Force:
-
30-500gf
-
Blade:
-
Roland CAMM-1 series blade
-
Ink Colors:
-
4/7/8 Color
-
Printing material:
-
Vinyl Sticker Banner Wrap Wallpaper
-
Resolution:
-
1200dpi Max
-
Blade Height:
-
Up to 1.5mm
-
Certification:
-
CE
Product Description
Specification
|
Model
|
|
VG2-640
|
VG2-540
|
||
|
Printing method
|
|
Piezo ink-jet method
|
|
||
|
|
Width
|
12.4 to 64 in. (315 to 1,625 mm)
|
10.8 to 54 in. (275 to 1,371 mm)
|
||
|
|
|
Max. 39 mil (1.0 mm) with liner, for printing
|
|
||
|
|
|
Max. 16 mil (0.4 mm) with liner and 9 mil (0.22 mm) without liner, for cutting
|
|
||
|
|
Roll outer diameter
|
Max. 8.3 in. (210 mm )
|
|
||
|
|
Roll weight
|
Max. 88 lb. (40 kg)
|
Max. 66 lb. (30 kg)
|
||
|
|
Core diameter
|
3 in. (76.2 mm) or 2 in. (50.8 mm)
|
|
||
|
Printing/cutting width
|
|
Max. 63 in. (1,600 mm)
|
Max. 53 in. (1,346 mm)
|
||
|
|
Type
|
TrueVIS INK 500 ml pouch (only white 250 ml)
|
|
||
|
|
|
8 colors (Cyan, Magenta, Yellow, Black, Light Black, Orange, Green, and White)
|
|
||
|
|
|
8 colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, and White)
|
|
||
|
|
|
8 colors (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, and Orange)
|
|
||
|
|
|
7 colors (Cyan, Magenta, Yellow, Black, Light Black, Orange and Green)
|
|
||
|
|
|
4 colors (Cyan, Magenta, Yellow, and Black)
|
|
||
|
Printing resolution (dots per inch)
|
|
Max. 1200 dpi
|
|
||
|
Cutting speed
|
|
0.4 to 11.8 in/s (10 to 300 mm/s)
|
|
||
|
Blade force
|
|
30 to 500 gf
|
|
||
|
Blade
|
Type
|
Roland CAMM-1 series blade
|
|
||
|
|
Offset
|
0.0 to 59.1 mil (0.000 to 1.500 mm)
|
|
||
|
Software resolution (when cutting)
|
|
0.98 mil/step (0.025 mm/step)
|
|
||
|
Distance accuracy (when printing)
|
|
Error of less than ±0.3% of distance traveled or ±11.8 mil (±0.3 mm), whichever is greater
|
|
||
|
Distance accuracy (when cutting)
|
|
Error of less than ±0.4% of distance traveled or ±11.8 mil (±0.3 mm), whichever is greater
|
|
||
|
|
|
When distance correction has been performed (when the setting for [CUTTING MENU] - [CALIBRATION] has been made): Error of less
than ±0.2% of distance traveled or ±3.9 mil (±0.1 mm), whichever is greater |
|
||
|
Repeatability (when cutting)
|
|
±3.9 mil (±0.1 mm) or less
|
|
||
|
Alignment accuracy for printing and cutting
|
|
±19.7 mil (±0.5 mm) or less
|
|
||
|
Alignment accuracy for printing and cutting when reloading media
|
|
Error of less than ±0.5% of distance traveled, or ±0.2 in. (±3 mm), whichever is greater
|
|
||
|
Media heating system
|
|
Print heater set temperature: 86 to 112°F (30 to 45°C)
|
|
||
|
|
|
Dryer set temperature: 30 to 50°C (86 to 122°F)
|
|
||
|
Connectivity
|
|
Ethernet (100BASE-TX/1000BASE-T, automatic switching)
|
|
||
|
Power-saving function
|
|
Automatic sleep feature
|
|
||
|
Power requirements
|
|
AC 100 to 120 V ±10%, 8.0 A, 50/60 Hz or
|
|
||
|
|
|
AC 220 to 240 V ±10%, 4.1 A, 50/60 Hz
|
|
||
|
Power consumption
|
During operation
|
Approx. 1,090 W
|
|
||
|
|
Sleep mode
|
Approx. 40 W
|
|
||
|
Acoustic noise level
|
During operation
|
63 dB (A) or less
|
|
||
|
|
During standby
|
53 dB (A) or less
|
|
||
|
Dimensions (with stand)
|
|
116 [W] × 28.8 [D] × 51.6 [H] in.
|
105.8 [W] × 28.8 [D] × 51.6 [H] in.
|
||
|
|
|
(2,945 (W) × 730 (D) × 1,310 (H) mm)
|
(2,685 (W) × 730 (D) × 1,310 (H) mm)
|
||
|
Weight (with stand)
|
|
451.9 lb. (204 kg)
|
421 lb. (188 kg)
|
||
|
Environment
|
During operation
|
Temperature: 68 to 90°F (20 to 32°C),
|
|
||
|
|
|
Humidity: 35 to 80%RH (no condensation)
|
|
||
|
|
Not operating
|
Temperature: 41 to 104°F (5 to 40°C),
|
|
||
|
|
|
Humidity: 20 to 80%RH (no condensation)
|
|
||
Packing & Delivery
In Carton Package
