Quick Details
-
Application:
-
Commercial Building
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CN Electric
-
Model Number:
-
CNX-L-3602
-
Product name:
-
Auto Frame Glass Revolving Door
-
Material:
-
Aluminum Alloy+Glass+Accessories
-
Position:
-
Commercial Building
-
Glass:
-
Laminated Glass
-
Type:
-
Revolving Door
-
Surface Treatment:
-
SS Cladding/powder-coated
-
Advantage:
-
Operate
-
Size:
-
Customized Size
-
Open Style:
-
Revolving
-
Program Selector:
-
Yes
Quick Details
-
Door Material:
-
Aluminum Alloy, Glass
-
Feature:
-
Windproof
-
Main Material:
-
Polymer
-
Application:
-
Commercial Building
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CN Electric
-
Model Number:
-
CNX-L-3602
-
Product name:
-
Auto Frame Glass Revolving Door
-
Material:
-
Aluminum Alloy+Glass+Accessories
-
Position:
-
Commercial Building
-
Glass:
-
Laminated Glass
-
Type:
-
Revolving Door
-
Surface Treatment:
-
SS Cladding/powder-coated
-
Advantage:
-
Operate
-
Size:
-
Customized Size
-
Open Style:
-
Revolving
-
Program Selector:
-
Yes
Product Description
Electrically Hotel Aluminum Frame Revolving Door Used Exterior Glass Doors Automatic Revolving Door Customized
2-wing luxury automatic revolving door
is an unique Revolving door with "
3 in 1 function
" which included Revolving door +Sliding door+ Balanced door. It combine the elegance,beauty, dignity,luxury characters and facilitate the pedestrian access by utilizing a perimeter drive that eliminates the need for a bulky center shaft.
Technical Data:
Power supply : 220V/50Hz
Rated current : 6A
Motor : 370W*2
Sliding door drive unit : 60W
Revolving door drive unit : 250W X 2=500W
Down lights : 40W
High speed adjustment range(revolving door) : 1- 4r.p.m.
Low speed adjustment range(revolving door) : 0.5-1.5 r.p.m
Rotational Noise: <42db
Torque of door leave: <2nm
Rated current : 6A
Motor : 370W*2
Sliding door drive unit : 60W
Revolving door drive unit : 250W X 2=500W
Down lights : 40W
High speed adjustment range(revolving door) : 1- 4r.p.m.
Low speed adjustment range(revolving door) : 0.5-1.5 r.p.m
Rotational Noise: <42db
Torque of door leave: <2nm
Specification
|
Inner Diameter (mm)
|
Outer Diameter (mm)
|
Entrance Width (mm)
|
Canopy Height (mm)
|
Pass Height (mm)
|
|
3020
|
3200
|
1400
|
300
|
2200
|
|
3220
|
3400
|
1500
|
300
|
2200
|
|
3420
|
3600
|
1600
|
300
|
2200
|
|
3690
|
3870
|
1757
|
300
|
2200
|
|
3880
|
4060
|
1850
|
300
|
2200
|
|
4020
|
4200
|
1920
|
300
|
2200
|
|
4420
|
4600
|
2150
|
300
|
2200
|
|
4620
|
4800
|
2260
|
300
|
2200
|
Features and Advantages
1.
Aluminum alloy die-casting molding frame, high strength, bright color, good surface finish.
2. A variety of materials and colors of surface decoration available: hair lines stainless steel, mirror stainless steel, aluminum fluorocarbon spraying, anodic oxidation, copper decoration etc.
3. The glass adopts laminated glass, tempered glass or special glass.
4. The ceiling is composed of radial wedge-shaped panels that coordinate with the material and decoration of the entire door.
5. Canopy made with plywood or metal plate for dustproof, outside made sealed for shower-proofing.
Energy saving, quiet, stable, long service life.
6. Digital program control system, easy operation.
7. Anti-squeeze function, anti-strike functionand and safety detection functions.
8. Slow speed for disabled. When the aged, children or disabled passing the door, press the disabled button, the door speed will slow down and rotate for 1 round, after that restore their normal function.
9. Revolving speed automatic lifting and adjusting function. Change the sensor condition according to the weather and visitors flow rate, to save time and energy.
2. A variety of materials and colors of surface decoration available: hair lines stainless steel, mirror stainless steel, aluminum fluorocarbon spraying, anodic oxidation, copper decoration etc.
3. The glass adopts laminated glass, tempered glass or special glass.
4. The ceiling is composed of radial wedge-shaped panels that coordinate with the material and decoration of the entire door.
5. Canopy made with plywood or metal plate for dustproof, outside made sealed for shower-proofing.
Energy saving, quiet, stable, long service life.
6. Digital program control system, easy operation.
7. Anti-squeeze function, anti-strike functionand and safety detection functions.
8. Slow speed for disabled. When the aged, children or disabled passing the door, press the disabled button, the door speed will slow down and rotate for 1 round, after that restore their normal function.
9. Revolving speed automatic lifting and adjusting function. Change the sensor condition according to the weather and visitors flow rate, to save time and energy.
